2011 Diesels Engine (35Hp)

Engine (35Hp)

The Bad Boy Mower parts diagram for the 2011 Diesels Engine (35Hp) is shown below. You may select the item you need by clicking on the Bad Boy Parts item number in the diagram or by finding it in the list below the diagram. BadBoyMowerParts.com has the parts diagrams for the 2011 Diesels models. Find all of your Bad Boy mowers 2011 Diesels parts here. We are your BadBoy mower parts source. Thanks for shopping with us for all of your Bad Boy parts needs. The Bad Boy parts diagram below is for the 2011 Diesels Engine (35Hp). If you are not able to find the Bad Boy parts for your 2011 Diesels please contact us using our Bad Boy parts live chat or toll free at 318.654.8520.

Bad Boy Mower Parts Lookup

2011 Diesels Engine (35Hp)
  Position Number SKU Product Title Price
1A 041-0010-00 041-0010-00 - Caterpillar/Perkins Fan Belt
$85.17
1 015-6050-00 015-6050-00 - Engine Fan - Diesel
$217.09
2 063-2010-00 063-2010-00 - Caterpillar Oil Filter
$31.02
3 063-2011-00 063-2011-00 - CAT FUEL FILTER BIG
$29.95
4 039-1010-00 039-1010-00 - Diesel Throttle Bracket 4 Tier
$5.49
5 017-3000-00 017-3000-00 - Stub shaft- Diesel
$245.99
7 018-2002-00 018-2002-00 - M6 X.50 X 20MM Class 8.8 Hex Bolts Zinc
$2.99
8 019-4008-00 019-4008-00 - 1/4 Lockwasher Zinc
$2.99
9 201-8005-00 201-8005-00 - Air Cleaner Support Diesel
$42.58
10 018-2010-00 018-2010-00 - 10-32 X 3/8 BS C/S 18-8 SS
$2.99
11 019-8051-00 019-8051-00 - 5/16 Lockwashwer Zinc
$2.99
12 019-8044-00 019-8044-00 - 5/16 USS Flat Washer Zinc
$2.99
13 018-2000-00 018-2000-00 - M6x1.0x20MM 8.8 Hex Bolts Zinc
$2.99
14 086-5001-00 086-5001-00 - 2007-2011 Diesel Oil Pressure Gauge w/Sender
$171.72
15 015-0005-00 015-0005-00 - Exhaust-28/35hp Caterpillar USE 015-0010-00 (obsolete)
use part #015-0010-00
$241.35
17 030-8000-00 030-8000-00 - 1/4x3/4 Set Screw-Diesel Exhau
$2.99
18 013-9001-00 013-9001-00 - 1/4-20 Hex Flange Nuts Zinc w/ Serrations
$2.99
19 019-5007-00 019-5007-00 - 1/2 Lockwasher Zinc
$2.99
20 018-6022-00 018-6022-00 - 12mm Bolt - Diesel
$2.99
21 018-2007-00 018-2007-00 - 5/16-18 X 1 GR 5 Hex Bolt Zinc
$2.99
22 013-8049-00 013-8049-00 - 5/16-18 Nylon Flange Nut
$2.99
23 201-8001-00 201-8001-00 - Hood Holder Diesel
$42.79
24 201-8008-00 201-8008-00 - Diesel Motor Side Support Right
$31.22
25 032-4050-00 032-4050-00 - Rubber Compression Mount Side Motor Mount-Diesel
$76.53
26 018-7016-00 018-7016-00 - 1/2-13 X 3 GR 5 Hex Bolts Zinc
$2.99
27 019-5010-00 019-5010-00 -.565x1.25x.095 Washer Brass
$2.99
28 013-7018-00 013-7018-00 - 1/2-13 Hex Nuts Zinc
$2.99
29 018-6049-00 018-6049-00 - 3/8-16 X 1 GR 5 Hex Bolts Zinc
$2.99
30 019-5029-00 019-5029-00 - 3/8 USS Flat Washer Zinc
$2.99
31 019-5037-00 019-5037-00 - 3/8 Lockwasher Zinc
$2.99
32 013-6014-00 013-6014-00 - 3/8-16 Hex Nuts Zinc
$2.99
34 013-8043-00 013-8043-00 - 5/16-18 Hex Nuts Zinc
$2.99
36 043-1000-00 043-1000-00 - 2010-2017 Diesel Muffler Guard (35hp)
$22.71
