2008 Pup and Lightning Seat Frame & Tank

Seat Frame & Tank

The Bad Boy Mower parts diagram for the 2008 Pup and Lightning Seat Frame & Tank is shown below. You may select the item you need by clicking on the Bad Boy Parts item number in the diagram or by finding it in the list below the diagram. BadBoyMowerParts.com has the parts diagrams for the 2008 Pup and Lightning models. Find all of your Bad Boy mowers 2008 Pup and Lightning parts here. We are your BadBoy mower parts source. Thanks for shopping with us for all of your Bad Boy parts needs. The Bad Boy parts diagram below is for the 2008 Pup and Lightning Seat Frame & Tank. If you are not able to find the Bad Boy parts for your 2008 Pup and Lightning please contact us using our Bad Boy parts live chat or toll free at 318.654.8520.

Bad Boy Mower Parts Lookup

2008 Pup and Lightning Seat Frame & Tank
  Position Number SKU Product Title Price
1A 085-4052-00 085-4052-00 - Pump/Wheel Motor Hydro Service Pack
$133.30
1 080-6010-00 080-6010-00 - Seat Frame (See Models Used On For Details)
$427.99
2 069-8054-00 069-8054-00 - Brake Handle Kit
$127.77
3 077-8073-00 077-8073-00 - Safety Switch (See Models Used On For Detail)
$10.99
4 018-8056-00 018-8056-00 - 10-24x1/2 Buttonhead SCS 18-8
$2.99
5 018-8050-00 018-8050-00 - 1/4-20 X 8 Carriage Bolts Zinc Bolt for Battery Hold Down
$2.99
6 013-8051-00 013-8051-00 - 1/4-20 Wing Nuts Zinc
$2.99
8 043-8929-00 043-8929-00 - Battery Hold Down Kit
$17.49
9 062-8013-00 062-8013-00 - Filter Head-Hydraulic Filter
$24.92
10 066-8048-00 066-8048-00 - Hydraulic Tank Cap
$22.23
11 064-8055-00 064-8055-00 - Short Brake Cable
$51.47
13 063-8014-00 063-8014-00 - Hydraulic Filter For Units with Pumps and Wheel Motors
$31.17
13 064-8056-00 064-8056-00 - Long Brake Cable
$53.49
14 024-5050-00 024-5050-00 - Filter Head Fitting, 1/2 x 1/2 , 208-108
$8.01
15 018-8052-00 018-8052-00 - 1/4-20 X 3/4 GR 5 Hex Bolts
$2.99
16 067-9016-00 067-9016-00 - Plastic Hydraulic Tank w/Strap OBSOLETE PART USE 067-2010-98 (obsolete)
use part #067-2010-22
$349.99
18 024-5205-00 024-5205-00 - Hose Barb, 3/8 x 3/8, 206-106
$8.74
19 024-5203-00 024-5203-00 - Fitting 4501-8-8
$11.75
20 055-8017-00 055-8017-00 - Throttle Cable - For Outlaws With FX850 Kawasaki Engines and All Pup/Lightning/AOS Gas Models without 32hp Briggs
$45.29
21 055-8021-00 055-8021-00 - Throttle Cable - Used on Pup/Lightning Models With 32hp Briggs Engines and all Outlaw models without FX850 Kawasaki Engines
$45.29
22 034-8045-00 034-8045-00 - Seat Spring
$20.49
23 014-8047-00 014-8047-00 - Rubber Cap Cover
$8.93
24 019-5029-00 019-5029-00 - 3/8 USS Flat Washer Zinc
$2.99
25 018-6012-00 018-6012-00 - 3/8 x 1 1/2 Bolt
$2.99
26 019-5037-00 019-5037-00 - 3/8 Lockwasher Zinc
$2.99
27 013-6014-00 013-6014-00 - 3/8-16 Hex Nuts Zinc
$2.99
28 018-5015-00 018-5015-00 - 5/16-18 X 1 Button Head Bolt
$2.99
29 019-8051-00 019-8051-00 - 5/16 Lockwashwer Zinc
$2.99
30 019-8044-00 019-8044-00 - 5/16 USS Flat Washer Zinc
$2.99
31 079-3401-00 079-3401-00 - 2007-2011 Pup/Lightning, 2011 Outlaw Extreme Instrument Panel
$23.78
32 056-8058-00 056-8058-00 - PTO Engager-Switch for Blades
$34.29
33A 067-5001-50 067-5001-50 - Left Fuel Tank (See Models Used On For Details)
$352.99
33 067-5000-50 067-5000-50 - Right Fuel Tank (See Models Used On For Details)
$352.99
34 066-8076-00 066-8076-00 - Non-Tethered Fuel Kelch Cap - 3.5 Neck
$32.05
35A 031-2006-00 031-2006-00 - Tank Support R (See Models Used On For Details)
$47.07
35 031-2007-00 031-2007-00 - Tank Support L (See Models Used On For Details)
$47.07
36 089-1000-00 089-1000-00 - Oil Light
$12.63
37 077-8076-00 077-8076-00 - Ignition Switch (key not included)
$21.39
38 042-9000-00 042-9000-00 - Ignition Key
$4.06
39 083-4013-00 083-4013-00 - Tachometer-N211-0100-1003
$74.89
40A 054-8017-00 054-8017-00 - 62" Choke Cable For MZ, ZT, CZT, Maverick, Rebel, Rogue, Outlaw XP Also Works On Outlaw & Pup/Lightning Models with 30hp Kohler (Not For 2013-2016 MZs With Kawasaki Engines)
$25.80
40 054-8016-00 054-8016-00 - 47" Choke Cable For AOS, Pup, Lightning, 2016-2018 Outlaw/Outlaw Extreme Units with Kawasaki FX730 & FX850 Engines and 2013-2016 MZ Units With Kawasaki Engines. (Will Not Work On Units With 30hp Engines)
$28.88
42 078-8077-00 078-8077-00 - Joystick - Deck Lift
$34.29
43 013-8047-00 013-8047-00 - 5/16-18 Nylon Insert Locknut Z inc Orange Nylon
$2.99
44 018-5200-00 018-5200-00 - 10-24 X 5/8 BS C/S 18-8 SS
$2.99
45 018-8059-00 018-8059-00 - 5/16-18x1-3/4 GR 5 Hex Bolts
$2.99
46 019-4008-00 019-4008-00 - 1/4 Lockwasher Zinc
$2.99
47 018-8063-00 018-8063-00 - 5/16-18 X 3/4 GR 5 Hex Bolts Z
$2.99
49 024-5342-00 024-5342-00 - Fitting 1/2 x 3/8 Barb 206-108
$7.95
