2011 Diesels Front Wheel Assembly

Front Wheel Assembly

The Bad Boy Mower parts diagram for the 2011 Diesels Front Wheel Assembly is shown below. You may select the item you need by clicking on the Bad Boy Parts item number in the diagram or by finding it in the list below the diagram. BadBoyMowerParts.com has the parts diagrams for the 2011 Diesels models. Find all of your Bad Boy mowers 2011 Diesels parts here. We are your BadBoy mower parts source. Thanks for shopping with us for all of your Bad Boy parts needs. The Bad Boy parts diagram below is for the 2011 Diesels Front Wheel Assembly. If you are not able to find the Bad Boy parts for your 2011 Diesels please contact us using our Bad Boy parts live chat or toll free at 318.654.8520.

Bad Boy Mower Parts Lookup

2011 Diesels Front Wheel Assembly
  Position Number SKU Product Title Price
1 019-5038-00 019-5038-00 - 5/8 Flat Washer
$2.99
2 018-3001-00 018-3001-00 - 5/8 x 5/8 Shoulder Bolt
$15.61
3 013-8050-00 013-8050-00 - 1/2-13 Nylon Insert Flange Nut Zinc Orange Nylon
$2.99
4 018-5006-00 018-5006-00 - 1/2-13 X 1-1/2 GR 5 Hex Bolt, Coarse Thread Bolt (For Use On Spindles Please Refer To Item Details)
$2.99
5 019-5007-00 019-5007-00 - 1/2 Lockwasher Zinc
$2.99
6 032-9002-00 032-9002-00 - Isolator - Red Dot
$70.97
7A 010-7003-98 010-7003-98 - Front Caster Bearing, Race, and seal kit (See Models Used On For Details)
$30.99
7 012-7003-00 012-7003-00 - Bearing Seal - Front Caster (See Models Used On For Details)
$10.21
8A 011-7002-00 011-7002-00 - Race (44610) Front Caster (See Models Used On For Details)
$2.99
8 010-7001-00 010-7001-00 - Tapered Roller Bearing - Caster- Race not included (See Models Used On For Details)
$6.26
9 022-1050-00 022-1050-00 - No-Flat 13 x 6.50-6 Orange Whe
$160.49
10 022-7010-00 022-7010-00 - 1 3/4" Bearing-Large Bore Front Wheel
$20.32
11 018-3002-00 018-3002-00 - 1/2 x 10 Bolt
$8.02
12 032-5052-00 032-5052-00 - Bronze Bushing - SF-2024-8 Front Suspension Fork
$4.81
13 025-5202-00 025-5202-00 - Front Wheel Spanner-All Models Except MZ
$10.44
14 019-3000-00 019-3000-00 - 1 Lock Washer
$3.29
15 037-0010-00 037-0010-00 - Front Suspension Fork Spindle Shaft - Black
$42.58
16 013-9004-00 013-9004-00 - 1" Nylock Nut 1/2 Nut - Fine
$3.62
17 014-7005-00 014-7005-00 - Dust Cover - Yellow Zinc
$9.34
