2010 CZT Transaxle

Transaxle

The Bad Boy Mower parts diagram for the 2010 CZT Transaxle is shown below. You may select the item you need by clicking on the Bad Boy Parts item number in the diagram or by finding it in the list below the diagram. BadBoyMowerParts.com has the parts diagrams for the 2010 CZT models. Find all of your Bad Boy mowers 2010 CZT parts here. We are your BadBoy mower parts source. Thanks for shopping with us for all of your Bad Boy parts needs. The Bad Boy parts diagram below is for the 2010 CZT Transaxle. If you are not able to find the Bad Boy parts for your 2010 CZT please contact us using our Bad Boy parts live chat or toll free at 318.654.8520.

Bad Boy Mower Parts Lookup

2010 CZT Transaxle
  Position Number SKU Product Title Price
1A 085-4051-00 085-4051-00 - 2020 Models and Older - ZT2800 - ZT3100 - ZT3200 & ALL ZT3400 Hydro Service Package With Expansion Tanks
$104.74
1 050-6000-00 050-6000-00 - ZT3400 Transaxle - Left (obsolete)
use part #050-6000-01
$877.39
2 050-6001-00 050-6001-00 - ZT3400 Transaxle - Right (obsolete)
use part #050-6001-01
$877.39
3 019-8051-00 019-8051-00 - 5/16 Lockwashwer Zinc
$2.99
4 019-8044-00 019-8044-00 - 5/16 USS Flat Washer Zinc
$2.99
5 013-3000-00 013-3000-00 - Acorn Lug Nut
$3.29
6 028-4801-00 028-4801-00 - Crossover Bar (See Models Used On For Detail)
$28.10
7 034-9000-00 034-9000-00 - SPRING (See Models Used On For Details)
$15.55
8 064-8055-00 064-8055-00 - Short Brake Cable
$51.47
9 013-8043-00 013-8043-00 - 5/16-18 Hex Nuts Zinc
$2.99
10 024-1200-00 024-1200-00 - Fitting, 3/8 x 3/8 45 Degree, 4603-6-6 (See Models Used On For Details)
$19.93
11 018-4701-00 018-4701-00 - 5/16-18 X 3 GR 5 Hex Bolt Zinc
$2.99
12 018-5344-00 018-5344-00 - 5/16 x 2 1/2 Bolt
$2.99
13 018-3000-00 018-3000-00 - 3/8-16 X 2 GR 5 Hex Bolts Zinc
$2.99
14 018-4007-00 018-4007-00 - 1/4-20 X 1 GR 5 Hex Bolts Zinc
$2.99
15 018-8052-00 018-8052-00 - 1/4-20 X 3/4 GR 5 Hex Bolts
$2.99
16 039-0053-00 039-0053-00 - Crossover Brake Bracket
$14.19
17A 022-5351-00 022-5351-00 - 23 x 10.50 - 12 Tire (One Tire Only)
$192.99
17B 022-7061-00 022-7061-00 - 12x8.5 Orange Wheel - Solid (One Rim Only)
$195.99
17C 022-5352-00 022-5352-00 - 23x10.50-12 Wheel Assembly (One Tire & Rim Assembly)
$267.99
17D 022-7062-00 022-7062-00 - 12 Orange Wheel - 48 and 52 Pu p Models
$113.62
17E 022-3000-00 022-3000-00 - 23x8.50-12 Tire Assembly (obsolete)
use part #022-3010-00
$265.99
17F 022-3025-00 022-3025-00 - 23 x 8.50 - 12 Turf Tire
$224.99
17G 022-3026-00 022-3026-00 - 12x7 Wheel-23 x 8.50 - 12 Tire
$74.89
17 022-5460-00 022-5460-00 - 23 x 10.50 -12 Assembly w/Negative Offset Wheel 54"CZT (One Tire & Rim Assy)
$266.99
18 018-5355-00 018-5355-00 - 5/16-18 X 6 GR 5 Hex Bolt Zinc
$2.99
19 025-5340-00 025-5340-00 -.365 ID X.752 OD X 3.313Lengt h Spacer Zinc
$8.74
20 063-1050-00 063-1050-00 - ZT Hydraulic Filter
$22.71
21 050-2072-00 050-2072-00 - Fan/Pulley Kit for CZT
$63.96
