$1031 - Bad Boy Mower Parts Lookup > 2014 > ZT Elite > 48\" Deck Assembly$

060-6048-00

In stock

060-6048-00 - 2013-2015 CZT, 2014-2016 ZT, 2016-2017 Maverick 48" Deck Shell

$1,196.14 Usually ship in 1-3 days

In stock

088-6006-00

In stock

088-6006-00 - Advanced Chute System

$249.00 Usually ship in 1-3 days

In stock

037-6015-50

In stock

037-6015-50 - Spindle Assembly

$199.99 Usually ship in 1-3 days

In stock

013-6014-00

In stock

013-6014-00 - 3/8-16 Hex Nuts Zinc

$2.99 Usually ship in 1-3 days

In stock

019-5037-00

In stock

019-5037-00 - 3/8" Lockwasher Zinc

$2.99 Usually ship in 1-3 days

In stock

019-6020-00

In stock

019-6020-00 - 1/2 Belleville Washer #K2000-G -150

$5.16 Usually ship in 1-3 days

In stock

019-5007-00

In stock

019-5007-00 - 1/2 Lockwasher Zinc

$2.99 Usually ship in 1-3 days

In stock

018-6019-00

In stock

018-6019-00 - 1/2-20 - 1-1/2 GR - Bolt Zinc, Fine Thread Bolt

$2.99 Usually ship in 1-3 days

In stock

042-6030-00

In stock

042-6030-00 - 1/4" - 1" Square Key

$4.81 Usually ship in 1-3 days

In stock

030-0050-00

In stock

030-0050-00 - 5/16 Set Screw

$2.99 Usually ship in 1-3 days

In stock

018-6020-00

In stock

018-6020-00 - 5/8-18 - 1-1/2 GR - Hex Bolt

$2.99 Usually ship in 1-3 days

In stock

019-4807-00

In stock

019-4807-00 - 5/8" Lockwasher Zinc

$2.99 Usually ship in 1-3 days

In stock

037-6023-00

037-6023-00 - Obsolete

Usually ship in 1-3 days

Newer version is available. Click to see 037-6029-00

018-5040-00

In stock

018-5040-00 - 3/8-16 - 1-1/4 GR - Hex Bolt

$2.99 Usually ship in 1-3 days

In stock

033-6003-00

In stock

033-6003-00 - 5" Spindle Deck Pulley - DB-80 (without set screw)

$42.58 Usually ship in 1-3 days

In stock

038-5350-00

In stock

038-5350-00 - 48"/50" High Lift Fusion Blade

$22.99 * Usually ship in 1-3 days

In stock

038-5000-00

In stock

038-5000-00 - 48"/50" Gator Mulching Blade

$22.99 * Usually ship in 1-3 days

In stock

15.1

038-1000-00

In stock

038-1000-00 - 48/50" Fusion Blades - 6-Pack (038-5350-00)

$118.99 * Usually ship in 1-3 days

In stock

15.2

038-1035-00

In stock

038-1035-00 - 48/50" Fusion Gator Mulching Blades - 6-Pack

$122.99 * Usually ship in 1-3 days

In stock

15.3

013-7021-00

In stock

013-7021-00 - 5/8-11 Nylon Insert Locknut Zinc

$2.99 Usually ship in 1-3 days

In stock

018-6059-00

In stock

018-6059-00 - 5/8-11 - 2-1/2 GR - Hex Bolts

$2.99 Usually ship in 1-3 days

In stock

048-6056-00

In stock

048-6056-00 - Toplink/Turnbuckle-Deck Adjust

$53.49 Usually ship in 1-3 days

In stock

013-8050-00

In stock

013-8050-00 - 1/2-13 Nylon Insert Flange Nut Zinc Orange Nylon

$2.99 Usually ship in 1-3 days

In stock

031-6010-00

031-6010-00 - Obsolete

Usually ship in 1-3 days

Newer version is available. Click to see 031-6020-00

032-5056-00

In stock

032-5056-00 - Flange Bushing-Deck Arms EF081108 - Frame Mounted

$5.82 Usually ship in 1-3 days

In stock

018-1090-00

In stock

018-1090-00 - 1/2-13x5 1/2 Hex Bolt Grade 5

$3.29 Usually ship in 1-3 days

In stock

018-6037-00

In stock

018-6037-00 - 1/2-13 - 2-1/4 GR - Hex Bolt

$2.99 Usually ship in 1-3 days

In stock

032-5057-00

In stock

032-5057-00 - Flange for Lower Deck Arm SF-1622-5

$14.11 Usually ship in 1-3 days

In stock

045-6043-00

In stock

045-6043-00 - Black Plastic Knob Spindle Cover

$4.39 Usually ship in 1-3 days

In stock

022-1000-00

In stock

022-1000-00 - Deck Wheel Only

$17.11 Usually ship in 1-3 days

In stock

025-5338-00

In stock

025-5338-00 -.502 ID X.750 OD - 1.500" Spacer Zinc

$3.62 Usually ship in 1-3 days

In stock

033-6001-00

In stock

033-6001-00 - 4 3/4 Idler Pulley

$31.22 Usually ship in 1-3 days

In stock

018-2018-00

In stock

018-2018-00 - 1/2 - 3 1/2 Flange Bolt - Gr 8

$3.62 Usually ship in 1-3 days

In stock

047-6050-00

In stock

047-6050-00 - CZT/ZT Deck Hanger Chain Assembly

$8.74 Usually ship in 1-3 days

In stock

041-1470-00

In stock

041-1470-00 - B147 Deck Belt

$87.39 Usually ship in 1-3 days

In stock

025-5339-00

In stock

025-5339-00 - .502 ID - 1.00 OD - 1.750 Length Spacer Zinc

$5.36 Usually ship in 1-3 days

In stock

033-5000-00

In stock

033-5000-00 - 5 3/4" Double Bearing Flat Idler Pulley

$56.77 Usually ship in 1-3 days

In stock

018-5019-00

In stock

018-5019-00 - 1/2-13 - 4 GR - Hex Bolt

$4.39 Usually ship in 1-3 days

In stock

039-6945-98

In stock

039-6945-98 - Deck Idler Assy

$78.08 Usually ship in 1-3 days

In stock

013-8050-00

In stock

013-8050-00 - 1/2-13 Nylon Insert Flange Nut Zinc Orange Nylon

$2.99 Usually ship in 1-3 days

In stock

039-6945-00

In stock

039-6945-00 - Idler Arm Bracket

$40.53 Usually ship in 1-3 days

In stock

018-7016-00

In stock

018-7016-00 - 1/2-13 - 3 GR 5 - Hex Bolts Zinc

$2.99 Usually ship in 1-3 days

In stock

025-5203-00

In stock

025-5203-00 - Spacer 3/4" OD - 1/2" ID - 0.75"

$3.29 Usually ship in 1-3 days

In stock

033-5000-00

In stock

033-5000-00 - 5 3/4" Double Bearing Flat Idler Pulley

$56.77 Usually ship in 1-3 days

In stock

018-5311-00

In stock

018-5311-00 - 5/8-11 - 4" GR - Hex Bolts Zinc

$4.06 Usually ship in 1-3 days

In stock

019-6017-00

In stock

019-6017-00 -.630 ID - 1.122 OD X.142 THK Flat Washer Nylon

$2.99 Usually ship in 1-3 days

In stock

013-5301-00

In stock

013-5301-00 - 5/8-11 Nylon Insert Jam Locknut Zinc

$2.99 Usually ship in 1-3 days

In stock

018-0008-00

In stock

018-0008-00 - 1/2 - 1 1/2 Carriage Bolt

$2.99 Usually ship in 1-3 days

In stock

034-2009-00

In stock

034-2009-00 - Deck/Pump Idler Spring

$18.18 Usually ship in 1-3 days

In stock

039-4870-00

In stock

039-4870-00 - Discharge Top Bracket, Rubber Chute Assembly

$42.52 Usually ship in 1-3 days

In stock

039-4871-00

In stock

039-4871-00 - 48/52 Discharge Lower Bracket Rubber Chute

$32.65 Usually ship in 1-3 days

In stock

210-6005-00

In stock

210-6005-00 - Rubber Discharge Chute

$59.91 Usually ship in 1-3 days

In stock

210-6005-48

In stock

210-6005-48 - Chute Assembly

$169.99 Usually ship in 1-3 days

In stock

48.1

013-8049-00

013-8049-00 – 5/16-18 Nylon Flange Nut

$2.99 Usually ship in 1-3 days

018-4703-00

In stock

018-4703-00 - 5/16-18 - 1-1/4 Carriage Bolt

$2.99 Usually ship in 1-3 days

In stock

206-6017-00

In stock

206-6017-00 - Discharge Chute Hanger-Deck

$39.03 Usually ship in 1-3 days

In stock

018-2007-00

In stock

018-2007-00 - 5/16-18 - 1 GR - Hex Bolt Zinc

$2.99 Usually ship in 1-3 days

In stock

019-6042-00

In stock

019-6042-00 -.36" ID Plastic Washer

$2.99 Usually ship in 1-3 days

In stock

013-8049-00

013-8049-00 – 5/16-18 Nylon Flange Nut

$2.99 Usually ship in 1-3 days

018-5250-00

In stock

018-5250-00 - 3/8-16 - 3/4 GR - Hex Bolts

$2.99 Usually ship in 1-3 days

In stock

013-5201-00

In stock

013-5201-00 - 3/8-16 Hex Flange Nuts Zinc w/ Serrations

$2.99 Usually ship in 1-3 days

In stock

018-0010-00

In stock

018-0010-00 - Deck Wheel Bolt

$6.48 Usually ship in 1-3 days

In stock

014-6010-00

014-6010-00 - Obsolete

Usually ship in 1-3 days

Newer version is available. Click to see 014-4000-00

019-5702-00

In stock

019-5702-00 - 1/2 SAE Flat Washer GR 8

$2.99 Usually ship in 1-3 days

In stock

The 2014 ZT Elite 48" Deck Assembly is a critical component that directly impacts the quality of your lawn. At BadBoyMowerParts.com, we provide high-quality Bad Boy Mower Parts like this deck assembly, which is designed to provide smooth and efficient cutting. Our Bad Boy Lawn Mower Parts are designed with durability in mind, so your deck assembly will last for years. When you shop for Bad Boy Parts Online, you’ll find that our parts are competitively priced and backed by excellent customer service. If you need help identifying the right deck assembly for your mower, our Bad Boy Mower Part diagrams are available to guide you. Additionally, we offer Free Shipping On Orders Over $100, so you can get the parts you need delivered directly to your door without the added shipping costs. Keep your 2014 ZT Elite in top shape with a new deck assembly from BadBoyMowerParts.com.
