2286 - Bad Boy Mower Parts Lookup > 2020 > Rebel > Drive Arm - Detail

031-0030-19

In stock

031-0030-19 - R Series Right Arm Rod Assembly 2019-2022 Rebel, Renegade - Rogue

$85.17 Usually ship in 1-3 days

In stock

114

013-0017-00

In stock

013-0017-00 - 3/8-16 Half Jam Nut

$2.99 Usually ship in 1-3 days

In stock

114.1

013-8050-00

In stock

013-8050-00 - 1/2-13 Nylon Insert Flange Nut Zinc Orange Nylon

$2.99 Usually ship in 1-3 days

In stock

114.2

018-0050-00

In stock

018-0050-00 - 1/2-13 - 3.25 Hex Bolt-Grade 5

$2.99 Usually ship in 1-3 days

In stock

114.3

018-0063-00

In stock

018-0063-00 - 3/8-16 - 1 SOCKET SET SCREW CUP POINT

$2.99 Usually ship in 1-3 days

In stock

114.4

019-8054-00

In stock

019-8054-00 - .505 ID - 1 OD X.128 THK Flat Washer Nylon

$2.99 Usually ship in 1-3 days

In stock

114.5

031-0014-00

In stock

031-0014-00 - Drive Arm Pivot

$24.92 Usually ship in 1-3 days

In stock

114.6

031-0030-00

In stock

031-0030-00 - Bad Boy Max Right Drive Arm Actuator

$46.78 Usually ship in 1-3 days

In stock

114.7

031-0031-19

In stock

031-0031-19 - R Series Left Arm Rod Assembly

$85.17 Usually ship in 1-3 days

In stock

115

013-0017-00

In stock

013-0017-00 - 3/8-16 Half Jam Nut

$2.99 Usually ship in 1-3 days

In stock

115.1

013-8050-00

In stock

013-8050-00 - 1/2-13 Nylon Insert Flange Nut Zinc Orange Nylon

$2.99 Usually ship in 1-3 days

In stock

115.2

018-0050-00

In stock

018-0050-00 - 1/2-13 - 3.25 Hex Bolt-Grade 5

$2.99 Usually ship in 1-3 days

In stock

115.3

018-0063-00

In stock

018-0063-00 - 3/8-16 - 1 SOCKET SET SCREW CUP POINT

$2.99 Usually ship in 1-3 days

In stock

115.4

019-8054-00

In stock

019-8054-00 - .505 ID - 1 OD X.128 THK Flat Washer Nylon

$2.99 Usually ship in 1-3 days

In stock

115.5

031-0014-00

In stock

031-0014-00 - Drive Arm Pivot

$24.92 Usually ship in 1-3 days

In stock

115.6

031-0031-00

In stock

031-0031-00 - Left Drive Arm Actuator 2019-2022 Rebel, Renegade - Rogue

$46.78 Usually ship in 1-3 days

In stock

115.7

031-9005-70

In stock

031-9005-70 - Left Hand Adjustable Steering Arm Kit 2019-2022 Rebel, Renegade - Rogue

$132.68 Usually ship in 1-3 days

In stock

118

013-8047-00

In stock

013-8047-00 - 5/16-18 Nylon Insert Locknut - Zinc

$2.99 Usually ship in 1-3 days

In stock

118.1

018-2020-18

In stock

018-2020-18 - 5/16-18 - 1 3/8" Button Head Torx Drive

$2.99 Usually ship in 1-3 days

In stock

118.2

018-5043-00

In stock

018-5043-00 - 3/8-16 - 1-1/4 Carriage Bolt

$2.99 Usually ship in 1-3 days

In stock

118.3

031-9005-00

In stock

031-9005-00 - Upper/Lower Steering Arm Casting 2019-2022 Rebel, Renegade - Rogue

$28.39 Usually ship in 1-3 days

In stock

118.4

031-9006-00

In stock

031-9006-00 - Steering Arm Tube

$42.79 Usually ship in 1-3 days

In stock

118.5

045-5000-00

In stock

045-5000-00 - Knob - Adjustable Steering Arm

$5.49 Usually ship in 1-3 days

In stock

118.6

069-4010-00

In stock

069-4010-00 - Black Steering Grip

$8.12 Usually ship in 1-3 days

In stock

118.7

031-9055-70

In stock

031-9055-70 - Right Hand Adjustable Steering Arm Kit 2019-2022 Rebel, Renegade - Rogue

$115.31 Usually ship in 1-3 days

In stock

119

013-8047-00

In stock

013-8047-00 - 5/16-18 Nylon Insert Locknut - Zinc

$2.99 Usually ship in 1-3 days

In stock

119.1

018-2020-18

In stock

018-2020-18 - 5/16-18 - 1 3/8" Button Head Torx Drive

$2.99 Usually ship in 1-3 days

In stock

119.2

018-5043-00

In stock

018-5043-00 - 3/8-16 - 1-1/4 Carriage Bolt

$2.99 Usually ship in 1-3 days

In stock

119.3

031-9005-00

In stock

031-9005-00 - Upper/Lower Steering Arm Casting 2019-2022 Rebel, Renegade - Rogue

$28.39 Usually ship in 1-3 days

In stock

119.4

031-9006-00

In stock

031-9006-00 - Steering Arm Tube

$42.79 Usually ship in 1-3 days

In stock

119.5

045-5000-00

In stock

045-5000-00 - Knob - Adjustable Steering Arm

$5.49 Usually ship in 1-3 days

In stock

119.6

069-4010-00

In stock

069-4010-00 - Black Steering Grip

$8.12 Usually ship in 1-3 days

In stock

119.7

035-0003-00

In stock

035-0003-00 - 2019 - 2022 Rebel Push Rod Assembly

$42.58 Usually ship in 1-3 days

In stock

126

013-6050-00

In stock

013-6050-00 - 5/16 LH Nut fits the 2019-2022 Outlaw Push Rods

$4.39 Usually ship in 1-3 days

In stock

126.1

013-6051-00

In stock

013-6051-00 - 3/8-24 Hex Jam Nuts Zinc

$2.99 Usually ship in 1-3 days

In stock

126.2

035-0003-01

In stock

035-0003-01 - 2019-2023 Rebel Rigid Push Rod

$35.30 Usually ship in 1-3 days

In stock

126.3

048-3000-00

In stock

048-3000-00 - Spherical Rod End-Outlaw Only

$14.19 Usually ship in 1-3 days

In stock

126.4

048-3002-00

In stock

048-3002-00 - Spherical Rod End - LH Thread - Rebel,Rogue,Renegade

$32.09 Usually ship in 1-3 days

In stock

126.5

The 2020 Rebel Drive Arm - Detail is an important part of your mower’s drive system, helping transmit power from the engine to the wheels. If the drive arm becomes worn or damaged, it can lead to poor performance or even complete failure of your mower. To replace or repair the drive arm, you’ll need the correct Bad Boy Mower Parts, which are easy to find with the help of Bad Boy Mower Part diagrams. These diagrams break down the components, making it simple to identify the parts that need replacing. Bad Boy Parts Online offers a wide selection of Bad Boy Lawn Mower Parts, including drive arms, pulleys, and more. By purchasing from BadBoyMowerParts.com, you can ensure you get quality parts that last. Plus, with Free Shipping On Orders Over $100, your order will be delivered to you without added costs. Get your 2020 Rebel Drive Arm - Detail today.
