3850 - Bad Boy Mower Parts Lookup > 2025 > Renegade - Diesel > Engine Assembly
013-8049-00 - 5/16-18 Nylon Flange Nut
013-8049-00

013-8049-00 – 5/16-18 Nylon Flange Nut

$2.99 Usually ship in 1-3 days
1
055-8018-75 - Bad Boy Mower Parts
055-8018-75

In stock

055-8018-75 - Diesel Thottle Cable ONLY

$32.09 Usually ship in 1-3 days

In stock

1A
014-1053-00 - Bad Boy Mower Parts
014-1053-00

In stock

014-1053-00 - Plastic Mesh Hose Loom 2019-2024 Renegade Diesel

$9.89 Usually ship in 1-3 days

In stock

2
015-0010-50 - Bad Boy Mower Parts
015-0010-50

In stock

015-0010-50 - 35/28 CAT Muffler Gasket

$17.02 Usually ship in 1-3 days

In stock

3
015-0096-06 - Bad Boy Mower Parts
015-0096-06

In stock

015-0096-06 - Oil Pressure Sensor for the Perkins 1100cc Diesel

$125.99 Usually ship in 1-3 days

In stock

4
015-0096-07 - Bad Boy Mower Parts
015-0096-07

In stock

015-0096-07 - Coolant Temperature Sensor for the Perkins 1100cc Diesel

$212.99 Usually ship in 1-3 days

In stock

5
015-0096-09 - Alternator for the Perkins 1100cc Diesel
015-0096-09

In stock

015-0096-09 - Alternator for the Perkins 1100cc Diesel

$829.99 Usually ship in 1-3 days

In stock

6
086-0017-00 - 2019 Deck Actuator Adaptor
015-0097-01

In stock

015-0097-01 - Starter for 015-0097-00

$1,099.99 Usually ship in 1-3 days

In stock

7
015-0097-02 - Alternator Belt for 015-0097-00
015-0097-02

In stock

015-0097-02 - Alternator Belt for 015-0097-00

$56.44 Usually ship in 1-3 days

In stock

8
086-0017-00 - 2019 Deck Actuator Adaptor
015-0097-03

In stock

015-0097-03 - Fuel Shutoff Solenoid for 015-0097-00

$235.99 Usually ship in 1-3 days

In stock

9
086-0017-00 - 2019 Deck Actuator Adaptor
015-0097-04

In stock

015-0097-04 - Fuel Priming Bulb Pump for 015-0097-00

$103.78 Usually ship in 1-3 days

In stock

10
015-0097-06 - Thermostat Gasket for 015-0097-00
015-0097-06

In stock

015-0097-06 - Thermostat Gasket for 015-0097-00

$21.39 Usually ship in 1-3 days

In stock

11
015-0097-07 - Fuel Pre-Filter for 015-0097-00
015-0097-07

In stock

015-0097-07 - Fuel Pre-Filter for 015-0097-00

$36.93 Usually ship in 1-3 days

In stock

12
015-0097-08 - Fuel Lift Pump for 015-0097-00
015-0097-08

In stock

015-0097-08 - Fuel Lift Pump for 015-0097-00

$229.99 Usually ship in 1-3 days

In stock

13
015-0097-11 - Oil Filler Cap for 015-0097-00
015-0097-11

In stock

015-0097-11 - Oil Filler Cap for 015-0097-00

$22.46 Usually ship in 1-3 days

In stock

14
015-0097-12 - Oil Level Dipstick for 015-0097-00
015-0097-12

In stock

015-0097-12 - Oil Level Dipstick for 015-0097-00

$53.49 Usually ship in 1-3 days

In stock

15
017-3001-00 - Bad Boy Mower Parts
017-3001-00

In stock

017-3001-00 - 2019-2024 Renegade Diesel Stub Shaft Double V

$150.99 Usually ship in 1-3 days

In stock

17
018-0016-00 - Bad Boy Mower Parts
018-0016-00

In stock

018-0016-00 - 5/16-18 - 1 Button Head Torx Drive Bolt

$2.99 Usually ship in 1-3 days

In stock

18
018-0024-00 - Bad Boy Mower Parts
018-0024-00

In stock

018-0024-00 - M6-1.0 - 16MM HEX BOLT

$2.99 Usually ship in 1-3 days

In stock

19
018-2001-00 - Bad Boy Mower Parts
018-2001-00

In stock

018-2001-00 - M8 - 1.25 - 25MM Class 10.9 He - Bolts Zinc

$2.99 Usually ship in 1-3 days

In stock

20
018-2006-00 - Bad Boy Mower Parts
018-2006-00

In stock

018-2006-00 - 5/16-18 - 1-1/4 GR - Hex Bolt

$2.99 Usually ship in 1-3 days

In stock

21
018-5321-00 - Bad Boy Mower Parts
018-5321-00

In stock

018-5321-00 - M8 - 1.25 - 20MM Hex Head Bolt

$2.99 Usually ship in 1-3 days

In stock

22
019-4008-00 - Bad Boy Mower Parts
019-4008-00

In stock

019-4008-00 - 1/4 Lockwasher Zinc

$2.99 Usually ship in 1-3 days

In stock

23
019-8044-00 - Bad Boy Mower Parts
019-8044-00

In stock

019-8044-00 - 5/16 USS Flat Washer Zinc

$2.99 Usually ship in 1-3 days

In stock

24
019-8051-00 - Bad Boy Mower Parts
019-8051-00

In stock

019-8051-00 - 5/16" Lockwasher Zinc

$2.99 Usually ship in 1-3 days

In stock

25
020-2000-00 - Bad Boy Mower Parts
020-2000-00

In stock

020-2000-00 - 3/32 - 1/2 Cotter Pins Zinc

$2.99 Usually ship in 1-3 days

In stock

26
024-0070-00 - Bad Boy Mower Parts
024-0070-00

In stock

024-0070-00 - 8mm - 1/8 mpt Adaptor - All Di esel Models

$50.28 Usually ship in 1-3 days

In stock

27
039-1010-00 - Bad Boy Mower Parts
039-1010-00

In stock

039-1010-00 - Diesel Throttle Bracket - Tier

$5.49 Usually ship in 1-3 days

In stock

28
039-1015-00 - Bad Boy Mower Parts
039-1015-00

In stock

039-1015-00 - Radiator Hose Clamp Bracket

$2.99 Usually ship in 1-3 days

In stock

29
044-2006-00 - Bad Boy Mower Parts
044-2006-00

In stock

044-2006-00 - 1/4 - 5/8 Clevis Pin

$2.99 Usually ship in 1-3 days

In stock

30
051-3003-00 - Bad Boy Mower Parts
051-3003-00

In stock

051-3003-00 - 2019 Diesel Radiator Hose Upper Dayco#71796

$49.63 Usually ship in 1-3 days

In stock

31
051-3004-00 - Bad Boy Mower Parts
051-3004-00

In stock

051-3004-00 - 2019 Diesel Air intake Hose

$14.97 Usually ship in 1-3 days

In stock

32
051-3005-00 - Bad Boy Mower Parts
051-3005-00

In stock

051-3005-00 - 2019 Diesel Radiator Hose Lower Dayco# 70808

$44.93 Usually ship in 1-3 days

In stock

33
063-2010-01 - Bad Boy Mower Parts
063-2010-01

In stock

063-2010-01 - Perkins Oil Filter

$29.37 Usually ship in 1-3 days

In stock

34
063-2011-01 - Bad Boy Mower Parts
063-2011-01

In stock

063-2011-01 - Perkins Fuel Filter

$26.96 Usually ship in 1-3 days

In stock

35
072-2002-00 - Bad Boy Mower Parts
072-2002-00

In stock

072-2002-00 - 2-1/2 Hose Clamp

$11.34 Usually ship in 1-3 days

In stock

36
072-2003-00 - Bad Boy Mower Parts
072-2003-00

In stock

072-2003-00 - 1 1/8 Hose Clamp

$5.82 Usually ship in 1-3 days

In stock

37
072-5000-00 - Bad Boy Mower Parts
072-5000-00

In stock

072-5000-00 - Diesel Hydraulic Hose Clamp

$7.28 Usually ship in 1-3 days

In stock

38
072-8090-00 - Bad Boy Mower Parts
072-8090-00

In stock

072-8090-00 - Diesel Clamp - 1 3/4 Vinyl

$3.63 Usually ship in 1-3 days

In stock

39
086-0003-00 - Bad Boy Mower Parts
086-0003-00

In stock

086-0003-00 - Alternator to Starter Cable

$7.79 Usually ship in 1-3 days

In stock

40
086-7003-00 - Bad Boy Mower Parts
086-7003-00

In stock

086-7003-00 - Temperature Sender- 2012 Gauge

$31.17 Usually ship in 1-3 days

In stock

42
086-7004-00 - Bad Boy Mower Parts
086-7004-00

In stock

086-7004-00 - Oil Pressure Sender- For 2012 and Newer Units

$119.99 Usually ship in 1-3 days

In stock

43

The 2025 Renegade - Diesel Engine Assembly provides unmatched power and efficiency, but routine maintenance with Bad Boy Mower Parts is key to longevity. At BadBoyMowerParts.com, we offer high-quality Bad Boy Lawn Mower Parts, including fuel injectors, air filters, cooling fans, and gaskets to keep your engine running strong. Using our Bad Boy Mower Part diagrams, you can quickly locate and order the right parts for seamless installation and repair. A properly maintained engine ensures better fuel efficiency, reduces emissions, and extends the lifespan of your mower. We stock Bad Boy Parts Online for quick and reliable ordering, ensuring you receive essential components fast. Plus, with Free Shipping On Orders Over $100, keeping your engine assembly in top shape is more affordable than ever. Don’t risk engine failure—order 2025 Renegade - Diesel Engine Assembly parts today and ensure maximum performance for years to come.
