The 2011 Diesels Rear Suspension is a key part of the mower's comfort and handling, helping to absorb shocks and reduce vibrations for a smoother ride. At BadBoyMowerParts.com, we provide high-quality Bad Boy Mower Parts, including the rear suspension for your 2011 Diesels. Our Bad Boy Mower Part diagrams make it easy to find the right suspension components for your mower, ensuring you get the perfect fit every time. We stock only genuine Bad Boy Lawn Mower Parts, so you can trust that the parts you receive are built to last. When you shop Bad Boy Parts Online, you can conveniently browse and order the parts you need. Plus, take advantage of Free Shipping On Orders Over $100, ensuring your rear suspension assembly arrives at your doorstep without any added shipping costs. Keep your mower’s ride smooth and comfortable with the right suspension parts.

|
| Position Number | SKU | Product Title | Price | ||
|---|---|---|---|---|---|
| 1 | 070-8000-00 | 070-8000-00 - Suspension Kit Wheel Motor (See Models Used On For Details) |
$291.91
|
||
| 3 | 032-9000-00 | 032-9000-00 - Isolator - Green Dot |
$70.97
|
||
| 4 | 018-2051-00 | 018-2051-00 - 5/8 x 10 Bolt Grade 8 |
$15.61
|
||
| 5 | 032-5051-00 | 032-5051-00 - Bronze Bushing - SF2024-24 Wheel Motor Cage |
$4.37
|
||
| 6 | 013-5020-00 | 013-5020-00 - 5/8-11 Hex Nuts Zinc |
$3.51
|
||
| 7 | 013-5301-00 | 013-5301-00 - 5/8-11 Nylon Insert Jam Locknut Zinc |
$2.99
|
||
| 8 | 024-6034-00 | 024-6034-00 - 1/4 Drive-in Grease Fitting |
$2.99
|
||
| 9 | 019-5007-00 | 019-5007-00 - 1/2 Lockwasher Zinc |
$2.99
|
||
| 10 | 018-6019-00 | 018-6019-00 - 1/2-20 X 1-1/2 Bolt Zinc, Fine Thread Bolt |
$2.99
|
||
| 11 | 019-5702-00 | 019-5702-00 - 1/2 SAE Flat Washer GR 8 |
$2.99
|
||
| 12A | 072-1000-00 | 072-1000-00 - Isolator Band Clamp |
$7.28
|
||
| 12 | 072-1000-98 | 072-1000-98 - Isolator Clamp Assembly |
$28.39
|
