2018 Walk Behind Front Fork Assembly

Front Fork Assembly

Find the parts for your 2018 Walk Behind Front Fork Assembly at BadBoyMowerParts.com. We have the Front Fork Assembly parts and all the Bad Boy Mower parts you need.

Bad Boy Mower Parts Lookup

2018 Walk Behind Front Fork Assembly
  Position Number SKU Product Title Price
1 010-1050-00 010-1050-00 - Front Fork Caster Bearing (See Models Used On For Details)
$18.39
2 013-8050-00 013-8050-00 - 1/2-13 Nylon Insert Flange Nut Zinc Orange Nylon
$2.99
3 013-9004-00 013-9004-00 - 1" Nylock Nut 1/2 Nut - Fine
$3.62
4 014-2025-00 014-2025-00 - 2017-2022 Caster Bearing Cover (See Models Used On For Details)
$2.99
5 018-0005-00 018-0005-00 - 1-14 X 5 BOLT GR 8 ZC YELLOW
$6.48
6 018-0035-00 018-0035-00 - 1/2-13 x 7 1/2 Grade 5 Hex Bolt
$4.83
7 022-7009-00 022-7009-00 - 1 3/8" Small Bore Bearing-Hoosier
$13.36
8 022-8049-00 022-8049-00 - 11x6.00-5 Front Assembly (One Tire and Rim Assy)
$99.39
9 023-0002-00 023-0002-00 - 2017-2022 Walkbehind & MZ Front Fork
$31.23
10 025-0003-00 025-0003-00 - Front Bearing Spacer
$14.04
11 025-0008-00 025-0008-00 - Front Wheel Spanner - MZ
$15.60
12 058-1000-00 058-1000-00 - MZ Bar Stop
$6.41
