2024 Rebel & Rebel X Front End

Front End

Find the parts for your 2024 at BadBoyMowerParts.com. We have the Front End parts and all the Bad Boy Mower parts you need.

Bad Boy Mower Parts Lookup

2024 Rebel & Rebel X Front End
  Position Number SKU Product Title Price
1 010-1050-00 010-1050-00 - Front Fork Caster Bearing (See Models Used On For Details)
$18.39
2 013-5202-00 013-5202-00 - 3/8 Nylock Flange Nut
$2.99
3 013-8050-00 013-8050-00 - 1/2-13 Nylon Insert Flange Nut Zinc Orange Nylon
$2.99
4 013-9004-00 013-9004-00 - 1" Nylock Nut 1/2 Nut - Fine
$3.62
5 014-2025-00 014-2025-00 - 2017-2022 Caster Bearing Cover (See Models Used On For Details)
$2.99
6 018-0026-00 018-0026-00 - 1-14 X 5 1/2 BOLT GR 8 ZC YEL
$13.90
7 018-0044-00 018-0044-00 - 3/8 x 2 1/2 Carriage Bolt
$2.99
8 018-7010-00 018-7010-00 - 1/2-13 X 9 GR 5 Hex Bolts Zinc
$5.82
9 022-3088-00 022-3088-00 - 13x6.50-6 Black No Flat Assy 2015-2019 Outlaw (Will Not Work On Renegade/Rogue), 2022 - 2024 Maverick, Maverick HD, Rebel
$156.21
10 023-0030-22 023-0030-22 2022-2023 Rebel Front Fork Weldment-Black
$112.34
11 025-0003-00 025-0003-00 - Front Bearing Spacer
$14.04
12 025-5202-00 025-5202-00 - Front Wheel Spanner-All Models Except MZ
$10.44
13 025-5337-00 025-5337-00 -.502x.750x1.125 Length Spacer
$2.99
14 029-8000-00 029-8000-00 - Front Bumper (See Models Used On For Details)
$31.17
16 030-7039-00 030-7039-00 - 14 X 1-1/2 HWA A T/S Zinc
$2.99
17 058-1000-00 058-1000-00 - MZ Bar Stop
$6.41
19 091-4063-00 091-4063-00 - Flying Bulldog Front Bumper Decal
$12.83
