2007 Diesel Seat Frame

Seat Frame

The Bad Boy Mower parts diagram for the 2007 Diesel Seat Frame is shown below. You may select the item you need by clicking on the Bad Boy Parts item number in the diagram or by finding it in the list below the diagram. BadBoyMowerParts.com has the parts diagrams for the 2007 Diesel models. Find all of your Bad Boy mowers 2007 Diesel parts here. We are your BadBoy mower parts source. Thanks for shopping with us for all of your Bad Boy parts needs. The Bad Boy parts diagram below is for the 2007 Diesel Seat Frame. If you are not able to find the Bad Boy parts for your 2007 Diesel please contact us using our Bad Boy parts live chat or toll free at 318.654.8520.

Bad Boy Mower Parts Lookup

2007 Diesel Seat Frame
  Position Number SKU Product Title Price
1A 085-4052-00 085-4052-00 - Pump/Wheel Motor Hydro Service Pack
$133.30
1 080-6010-00 080-6010-00 - Seat Frame (See Models Used On For Details)
$427.99
2 069-8054-00 069-8054-00 - Brake Handle Kit
$127.77
3 077-8073-00 077-8073-00 - Safety Switch (See Models Used On For Detail)
$10.99
4 018-8056-00 018-8056-00 - 10-24x1/2 Buttonhead SCS 18-8
$2.99
5 018-8051-00 018-8051-00 - 1/4-20 X 9 Carriage Bolts Zinc
$2.99
6 013-8051-00 013-8051-00 - 1/4-20 Wing Nuts Zinc
$2.99
8 043-8929-00 043-8929-00 - Battery Hold Down Kit
$17.49
9 062-8013-00 062-8013-00 - Filter Head-Hydraulic Filter
$24.92
10 066-8048-00 066-8048-00 - Hydraulic Tank Cap
$22.23
11 064-8055-00 064-8055-00 - Short Brake Cable
$51.47
13 063-8014-00 063-8014-00 - Hydraulic Filter For Units with Pumps and Wheel Motors
$31.17
14 024-5050-00 024-5050-00 - Filter Head Fitting, 1/2 x 1/2 , 208-108
$8.01
15 018-8052-00 018-8052-00 - 1/4-20 X 3/4 GR 5 Hex Bolts
$2.99
16 067-9016-00 067-9016-00 - Plastic Hydraulic Tank w/Strap OBSOLETE PART USE 067-2010-98 (obsolete)
use part #067-2010-22
$349.99
18 024-5205-00 024-5205-00 - Hose Barb, 3/8 x 3/8, 206-106
$8.74
19 024-5203-00 024-5203-00 - Fitting 4501-8-8
$11.75
20 055-8018-00 055-8018-00 - Throttle Cable (See Models Used On For Details)
$60.92
21 034-8045-00 034-8045-00 - Seat Spring
$20.49
22 014-8047-00 014-8047-00 - Rubber Cap Cover
$8.93
23 019-5029-00 019-5029-00 - 3/8 USS Flat Washer Zinc
$2.99
24 018-6012-00 018-6012-00 - 3/8 x 1 1/2 Bolt
$2.99
25 019-5037-00 019-5037-00 - 3/8 Lockwasher Zinc
$2.99
26 013-6014-00 013-6014-00 - 3/8-16 Hex Nuts Zinc
$2.99
27 019-8051-00 019-8051-00 - 5/16 Lockwashwer Zinc
$2.99
28 013-8043-00 013-8043-00 - 5/16-18 Hex Nuts Zinc
$2.99
30 013-8047-00 013-8047-00 - 5/16-18 Nylon Insert Locknut Z inc Orange Nylon
$2.99
31 018-5200-00 018-5200-00 - 10-24 X 5/8 BS C/S 18-8 SS
$2.99
32 018-8059-00 018-8059-00 - 5/16-18x1-3/4 GR 5 Hex Bolts
$2.99
33 019-4008-00 019-4008-00 - 1/4 Lockwasher Zinc
$2.99
34 018-8063-00 018-8063-00 - 5/16-18 X 3/4 GR 5 Hex Bolts Z
$2.99
36 077-6000-00 077-6000-00 - Momentary Start Switch Preheat Button for Diesel
$21.39
37 064-8056-00 064-8056-00 - Long Brake Cable
$53.49
