The Bad Boy Mower parts diagram for the 2013 ZT Elite Spindle Assembly is shown below. You may select the item you need by clicking on the Bad Boy Parts item number in the diagram or by finding it in the list below the diagram. BadBoyMowerParts.com has the parts diagrams for the 2013 ZT Elite models. Find all of your Bad Boy mowers 2013 ZT Elite parts here. We are your BadBoy mower parts source. Thanks for shopping with us for all of your Bad Boy parts needs. The Bad Boy parts diagram below is for the 2013 ZT Elite Spindle Assembly. If you are not able to find the Bad Boy parts for your 2013 ZT Elite please contact us using our Bad Boy parts live chat or toll free at 318.654.8520.
Position Number | SKU | Product Title | Price | ||
---|---|---|---|---|---|
1.0 | 037-6015-50 | 037-6015-50 - Spindle Assembly (See Models Used On For Detail) |
$213.99
|
||
1 | 037-6017-50 |
037-6017-50 - Compact Outlaw / Maverick / Walkbehind / ZT & 2007 Pup Aluminum Spindle Housing (obsolete) use part #037-6015-50 |
$213.99
|
||
2 | 037-8050-00 | 037-8050-00 - Tube Spacer For Spindle Shaft - Small Spindle |
$8.69
|
||
3 | 037-6023-00 |
037-6023-00 - Spindle Bearing (See Models Used On For Details) (obsolete) use part #037-6029-00 |
$42.58
|
||
4 | 037-6026-00 | 037-6026-00 - Short Spindle Shaft w/Locking Collar - No Grooved Shaft |
$83.77
|
||
5 | 037-8002-00 | 037-8002-00 - Dust Cover (Used on 037-4000-00 & 037-6015-50) |
$11.76
|
||
6 | 037-9050-00 | 037-9050-00 - Collar Spacer - Top of Spindle (See Models Used On For Details) |
$7.28
|
