2015 Outlaw & Outlaw Extreme Seat Assembly

Seat Assembly

BadBoyMowerParts.com has the parts diagrams for the 2015 Outlaw & Outlaw Extreme models. Find all of your Bad Boy parts for your 2015 Outlaw & Outlaw Extreme parts here. We are your Bad Boy mower parts source. Thanks for shopping with us for all of your Bad Boy parts needs. The Bad Boy parts diagram below is for the 2015 Outlaw & Outlaw Extreme Seat Assembly. If you are not able to find the Bad Boy parts for your 2015 Outlaw & Outlaw Extreme please contact us using our Bad Boy parts live chat or toll free at 318.654.8520.

Bad Boy Mower Parts Lookup

2015 Outlaw & Outlaw Extreme Seat Assembly
  Position Number SKU Product Title Price
1 080-5100-00 080-5100-00 - Outlaw Seat Bracket 2015
$427.99
2 014-2100-00 014-2100-00 - Outlaw Cooler Cover
$21.39
3 026-2006-00 026-2006-00 - Seat Plate (See Models Used On For Details)
$99.32
4 018-8065-00 018-8065-00 - 5/16-18 X 1 Carriage Bolt Zinc
$2.99
5 019-6042-00 019-6042-00 -.360 ID Plastic Washer
$2.99
6 013-5202-00 013-5202-00 - 3/8 Nylock Flange Nut
$2.99
7 018-5043-00 018-5043-00 - 3/8-16 X 1-1/4 Carriage Bolt
$2.99
8 030-7042-00 030-7042-00 - 5/16 x 3/4 Hex Washer Type F
$2.99
9 019-6050-00 019-6050-00 -.360 ID Black Plastic Washer
$2.99
10 013-8049-00 013-8049-00 - 5/16-18 Nylon Flange Nut
$2.99
11 071-5060-00 071-5060-00 - 2011-2018 Outlaw Models & 2019 Rebel Seat
$748.99
12 019-8051-00 019-8051-00 - 5/16 Lockwashwer Zinc
$2.99
13 013-9002-00 013-9002-00 - 5/16-18 Hex Flange Nuts Zinc w /Serrations
$2.99
14 036-5300-00 036-5300-00 - Seat Switch Adaptor
$15.55
15 064-8081-00 064-8081-00 - Seat Cable (See Models Used On For Details)
$15.60
16 013-8043-00 013-8043-00 - 5/16-18 Hex Nuts Zinc
$2.99
17 018-8063-00 018-8063-00 - 5/16-18 X 3/4 GR 5 Hex Bolts Z
$2.99
18 034-1444-00 034-1444-00 - Rubber Cone-1621-153 (obsolete)
use part #034-8045-98
$29.80
19 077-8073-00 077-8073-00 - Safety Switch (See Models Used On For Detail)
$10.99
20 018-8058-00 018-8058-00 - 10-24 X 1 BS C/S 18-8 SS
$2.99
21 013-5019-00 013-5019-00 - 10-24 Nylon Insert Locknut Zin c Orange Nylon
$2.99
22 025-6041-00 025-6041-00 - Switch Block Plastic
$2.99
23 064-8056-00 064-8056-00 - Long Brake Cable
$53.49
24 054-8017-00 054-8017-00 - 62" Choke Cable For MZ, ZT, CZT, Maverick, Rebel, Rogue, Outlaw XP Also Works On Outlaw & Pup/Lightning Models with 30hp Kohler (Not For 2013-2016 MZs With Kawasaki Engines)
$25.80
25 013-6051-00 013-6051-00 - 3/8-24 Hex Jam Nuts Zinc
$2.99
26 018-0009-00 018-0009-00 - 3/8 x 1 3/4 Carriage Bolt
$2.99
27A 055-2013-00 055-2013-00 - Throttle/Brake Head Ball
$12.48
27 055-2012-00 055-2012-00 - Universal Throttle/Brake Lever (Knob Not Included)
$25.54
28 018-5200-00 018-5200-00 - 10-24 X 5/8 BS C/S 18-8 SS
$2.99
29 018-4700-00 018-4700-00 - 3/8-16 X 3 GR 5 Hex Bolts Zinc
$2.99
30 019-5029-00 019-5029-00 - 3/8 USS Flat Washer Zinc
$2.99
31 018-0024-00 018-0024-00 - M6-1.0 X 16MM HEX BOLT CL 8
$2.99
32 067-0020-00 067-0020-00 - Carbon Canister ZT,CZT,Outlaw RY652CC
$62.40
33 051-8072-00 051-8072-00 - 1/4" Vinyl Tubing - Black (Priced Per Foot)
$2.99
34 051-8073-00 051-8073-00 - 3/16" Vinyl Tubing (Priced Per Foot)
$2.99
35 072-8073-00 072-8073-00 - 3/16" Vinyl Hose Clamp
$2.99
36 072-8070-00 072-8070-00 - Tank Hose Clamp 3/16 Vinyl Hose (See Models Used On For Detail)
$2.99
37 039-0150-00 039-0150-00 - Brake Cable Adapter Bracket2015 Outlaws/XP
$18.72
38 018-1080-00 018-1080-00 - 12-24 x 1/2 HWH Bolt - Safety Switch-ZT
$2.99
39 013-9005-00 013-9005-00 - 5/16-18 Nylock Jam Nut
$2.99
40 069-1000-00 069-1000-00 - Brake Handle Cam Over
$7.28
41 069-7000-00 069-7000-00 - Rubber Brake Grip
$6.41
42 032-5053-00 032-5053-00 - Bronze Bushing SF-1220-8 2013 & UP CZT/ZT Brake Bushing
$2.99
43 013-0009-00 013-0009-00 - 3/8-16 Hex Flange Top L/N
$2.99
44 031-2041-00 031-2041-00 - 2015 Outlaw Tank Support(Left)
$58.84
45 031-2040-00 031-2040-00 - 2015-2018 Outlaw Tank Support (Right)
$58.84
46A 064-0045-00 064-0045-00 - 2015 Outlaw Seat Latch Assy
$32.10
46 064-0047-00 064-0047-00 - 2015 Seat Latch Cable (See Models Used On For Details)
$14.19
47 064-0046-00 064-0046-00 - 2015 Seat Latch Toggle
$28.39
48 018-9000-00 018-9000-00 - 3/16 Pop Rivet
$2.99
49 014-2000-00 014-2000-00 - Black Plug - 5/8" Head
$2.99
50 034-1075-00 034-1075-00 - Torsion Spring-Seat Latch
$5.49
51 031-0200-00 031-0200-00 - Seat Latch Lever
$2.99
52 018-0012-00 018-0012-00 - 5/16-18 X 2 HEX C/S (GR.5) ZC
$2.99
53 018-4007-00 018-4007-00 - 1/4-20 X 1 GR 5 Hex Bolts Zinc
$2.99
54 018-4702-00 018-4702-00 - 1/4-20 X 1-1/4 GR 5 Hex Bolt
$2.99
55 013-2050-00 013-2050-00 - 1/4-20 Nylon Insert Flange Nut
$2.99
56 025-2000-00 025-2000-00 -.380x.735x.470 Nylon Spacer
$2.99
57 018-2007-00 018-2007-00 - 5/16-18 X 1 GR 5 Hex Bolt Zinc
$2.99
58 018-1010-00 018-1010-00 - 3/8-16x3-1/2 Grade 5 Hex Bolt
$2.99
59 025-0001-00 025-0001-00 - 2015-2022 Brake Lever Spacer
$8.01
60 018-4706-00 018-4706-00 - 3/8 x 1 1/2 Carriage Bolt
$2.99
61A 055-8017-00 055-8017-00 - Throttle Cable - For Outlaws With FX850 Kawasaki Engines and All Pup/Lightning/AOS Gas Models without 32hp Briggs
$45.29
61 055-8021-00 055-8021-00 - Throttle Cable - Used on Pup/Lightning Models With 32hp Briggs Engines and all Outlaw models without FX850 Kawasaki Engines
$45.29
