2015 Outlaw XP Seat Frame

Seat Frame

BadBoyMowerParts.com has the parts diagrams for the 2015 Outlaw XP models. Find all of your Bad Boy parts for your 2015 Outlaw XP parts here. We are your BadBoy mower parts source. Thanks for shopping with us for all of your Bad Boy parts needs. The Bad Boy parts diagram below is for the 2015 Outlaw XP Seat Frame. If you are not able to find the Bad Boy parts for your 2015 Outlaw XP please contact us using our Bad Boy parts live chat or toll free at 318.654.8520.

Bad Boy Mower Parts Lookup

2015 Outlaw XP Seat Frame
  Position Number SKU Product Title Price
1A 085-4052-00 085-4052-00 - Pump/Wheel Motor Hydro Service Pack
$133.30
1 080-5100-00 080-5100-00 - Outlaw Seat Bracket 2015
$427.99
2 014-2100-00 014-2100-00 - Outlaw Cooler Cover
$21.39
3 026-2006-00 026-2006-00 - Seat Plate (See Models Used On For Details)
$99.32
4 018-8065-00 018-8065-00 - 5/16-18 X 1 Carriage Bolt Zinc
$2.99
5 019-6042-00 019-6042-00 -.360 ID Plastic Washer
$2.99
6 013-5202-00 013-5202-00 - 3/8 Nylock Flange Nut
$2.99
7 018-5043-00 018-5043-00 - 3/8-16 X 1-1/4 Carriage Bolt
$2.99
8 030-7042-00 030-7042-00 - 5/16 x 3/4 Hex Washer Type F
$2.99
9 013-8049-00 013-8049-00 - 5/16-18 Nylon Flange Nut
$2.99
10 019-6050-00 019-6050-00 -.360 ID Black Plastic Washer
$2.99
11 071-5060-00 071-5060-00 - 2011-2018 Outlaw Models & 2019 Rebel Seat
$748.99
12 019-8051-00 019-8051-00 - 5/16 Lockwashwer Zinc
$2.99
13 013-9002-00 013-9002-00 - 5/16-18 Hex Flange Nuts Zinc w /Serrations
$2.99
14 036-5300-00 036-5300-00 - Seat Switch Adaptor
$15.55
15 064-8081-00 064-8081-00 - Seat Cable (See Models Used On For Details)
$15.60
16 013-8043-00 013-8043-00 - 5/16-18 Hex Nuts Zinc
$2.99
17 018-8063-00 018-8063-00 - 5/16-18 X 3/4 GR 5 Hex Bolts Z
$2.99
18 034-1444-00 034-1444-00 - Rubber Cone-1621-153 (obsolete)
use part #034-8045-98
$29.80
19 077-8073-00 077-8073-00 - Safety Switch (See Models Used On For Detail)
$10.99
20 018-8058-00 018-8058-00 - 10-24 X 1 BS C/S 18-8 SS
$2.99
21 013-5019-00 013-5019-00 - 10-24 Nylon Insert Locknut Zin c Orange Nylon
$2.99
22 025-6041-00 025-6041-00 - Switch Block Plastic
$2.99
23 054-8017-00 054-8017-00 - 62" Choke Cable For MZ, ZT, CZT, Maverick, Rebel, Rogue, Outlaw XP Also Works On Outlaw & Pup/Lightning Models with 30hp Kohler (Not For 2013-2016 MZs With Kawasaki Engines)
$25.80
24 013-6051-00 013-6051-00 - 3/8-24 Hex Jam Nuts Zinc
$2.99
25 018-0009-00 018-0009-00 - 3/8 x 1 3/4 Carriage Bolt
$2.99
26 018-1010-00 018-1010-00 - 3/8-16x3-1/2 Grade 5 Hex Bolt
$2.99
27 019-5029-00 019-5029-00 - 3/8 USS Flat Washer Zinc
$2.99
28A 055-2013-00 055-2013-00 - Throttle/Brake Head Ball
$12.48
28 055-2012-00 055-2012-00 - Universal Throttle/Brake Lever (Knob Not Included)
$25.54
29 018-5200-00 018-5200-00 - 10-24 X 5/8 BS C/S 18-8 SS
$2.99
30 018-4700-00 018-4700-00 - 3/8-16 X 3 GR 5 Hex Bolts Zinc
$2.99
31 018-0024-00 018-0024-00 - M6-1.0 X 16MM HEX BOLT CL 8
$2.99
32 067-0020-00 067-0020-00 - Carbon Canister ZT,CZT,Outlaw RY652CC
$62.40
33 051-8072-00 051-8072-00 - 1/4" Vinyl Tubing - Black (Priced Per Foot)
$2.99
34 051-8073-00 051-8073-00 - 3/16" Vinyl Tubing (Priced Per Foot)
$2.99
35 072-8073-00 072-8073-00 - 3/16" Vinyl Hose Clamp
$2.99
36 072-8070-00 072-8070-00 - Tank Hose Clamp 3/16 Vinyl Hose (See Models Used On For Detail)
$2.99
38 013-5041-00 013-5041-00 - 3/8-16 Nylon Insert Locknut Zi nc Orange Nylon
$2.99
39 019-7040-00 019-7040-00 - 1/4 USS Flat Washer Zinc
$2.99
40 051-8064-00 051-8064-00 - 1/2 Clear Braided Hose PRICED/ FOOT
$2.99
41 072-8066-00 072-8066-00 - 1/2 Hose Clamp
$2.99
42 051-8063-00 051-8063-00 - 3/8 Clear Hose PRICED PER FOOT
$2.99
43 072-8065-00 072-8065-00 - 3/8 Hose Clamp - CTB-16-STFS
$2.99
44 039-0150-00 039-0150-00 - Brake Cable Adapter Bracket2015 Outlaws/XP
$18.72
45 018-1080-00 018-1080-00 - 12-24 x 1/2 HWH Bolt - Safety Switch-ZT
$2.99
46 013-9005-00 013-9005-00 - 5/16-18 Nylock Jam Nut
$2.99
47 069-1000-00 069-1000-00 - Brake Handle Cam Over
$7.28
48 069-7000-00 069-7000-00 - Rubber Brake Grip
$6.41
49 032-5053-00 032-5053-00 - Bronze Bushing SF-1220-8 2013 & UP CZT/ZT Brake Bushing
$2.99
50 013-0009-00 013-0009-00 - 3/8-16 Hex Flange Top L/N
$2.99
51 031-2041-00 031-2041-00 - 2015 Outlaw Tank Support(Left)
$58.84
52 031-2040-00 031-2040-00 - 2015-2018 Outlaw Tank Support (Right)
$58.84
53A 064-0045-00 064-0045-00 - 2015 Outlaw Seat Latch Assy
$32.10
53 064-0047-00 064-0047-00 - 2015 Seat Latch Cable (See Models Used On For Details)
$14.19
54 064-0046-00 064-0046-00 - 2015 Seat Latch Toggle
$28.39
55 064-9001-00 064-9001-00 - 2015-2018 XP Brake Cable-57.5"
$51.47
56 064-9000-00 064-9000-00 - 2015-2018 Outlaw XP Brake Cable-33"
$51.47
57 018-9000-00 018-9000-00 - 3/16 Pop Rivet
$2.99
58 018-4007-00 018-4007-00 - 1/4-20 X 1 GR 5 Hex Bolts Zinc
$2.99
59 013-2050-00 013-2050-00 - 1/4-20 Nylon Insert Flange Nut
$2.99
60 025-2000-00 025-2000-00 -.380x.735x.470 Nylon Spacer
$2.99
61 034-1075-00 034-1075-00 - Torsion Spring-Seat Latch
$5.49
62 031-0200-00 031-0200-00 - Seat Latch Lever
$2.99
63 018-0012-00 018-0012-00 - 5/16-18 X 2 HEX C/S (GR.5) ZC
$2.99
64 018-4702-00 018-4702-00 - 1/4-20 X 1-1/4 GR 5 Hex Bolt
$2.99
65 018-2007-00 018-2007-00 - 5/16-18 X 1 GR 5 Hex Bolt Zinc
$2.99
66 062-8013-00 062-8013-00 - Filter Head-Hydraulic Filter
$24.92
67 024-5050-00 024-5050-00 - Filter Head Fitting, 1/2 x 1/2 , 208-108
$8.01
68 063-8014-00 063-8014-00 - Hydraulic Filter For Units with Pumps and Wheel Motors
$31.17
69 024-5342-00 024-5342-00 - Fitting 1/2 x 3/8 Barb 206-108
$7.95
70 018-8052-00 018-8052-00 - 1/4-20 X 3/4 GR 5 Hex Bolts
$2.99
71 019-4008-00 019-4008-00 - 1/4 Lockwasher Zinc
$2.99
72 025-0001-00 025-0001-00 - 2015-2022 Brake Lever Spacer
$8.01
73 018-4706-00 018-4706-00 - 3/8 x 1 1/2 Carriage Bolt
$2.99
74A 055-8017-00 055-8017-00 - Throttle Cable - For Outlaws With FX850 Kawasaki Engines and All Pup/Lightning/AOS Gas Models without 32hp Briggs
$45.29
74 055-8021-75 055-8021-75 - 52" Outlaw Throttle Cable ONLY (Excludes Outlaws w/ FX850 Kawasaki Engines), Also Fits 2019-2022 Rebel, Renegade, Rogue, and Revolt (27hp Kawasaki, Yamaha, and Kohler, 29.5 EFI Kawasaki, 33hp EFI Kohler and Yamaha, 37hp EFI Vanguard)
$28.88
