2011 CZT 50" Deck Assembly

50" Deck Assembly

The Bad Boy Mower parts diagram for the 2011 CZT 50" Deck is shown below. You may select the item you need by clicking on the Bad Boy Parts item number in the diagram or by finding it in the list below the diagram. BadBoyMowerParts.com has the parts diagrams for the 2011 CZT models. Find all of your Bad Boy mowers 2011 CZT parts here. We are your BadBoy mower parts source. Thanks for shopping with us for all of your Bad Boy parts needs. The Bad Boy parts diagram below is for the 2011 CZT 50" Deck. If you are not able to find the Bad Boy parts for your 2011 CZT please contact us using our Bad Boy parts live chat or toll free at 318.654.8520.

Bad Boy Mower Parts Lookup

2011 CZT 50" Deck Assembly
  Position Number SKU Product Title Price
1A 088-6006-00 088-6006-00 - Advanced Chute System For Select 42", 48", 50", 52" Mowers & select 54", 2022 - 2024 Maverick HD 42", Will Not Fit MZ
$266.99
1 018-5040-00 018-5040-00 - 3/8-16 X 1-1/4 GR 5 Hex Bolt
$2.99
2 019-5037-00 019-5037-00 - 3/8 Lockwasher Zinc
$2.99
3 013-6014-00 013-6014-00 - 3/8-16 Hex Nuts Zinc
$2.99
4 018-5250-00 018-5250-00 - 3/8-16 X 3/4 GR 5 Hex Bolts
$2.99
5 013-5201-00 013-5201-00 - 3/8-16 Hex Flange Nuts Zinc w/ Serrations
$2.99
6 025-5338-00 025-5338-00 -.502 ID X.750 OD X 1.500 Leng th Spacer Zinc
$3.62
7 033-6001-00 033-6001-00 - 4 3/4 Idler Pulley (See Models Used On For Details)
$31.22
8 033-6003-00 033-6003-00 - 5" Spindle Deck Pulley - DB-80 (without set screw) (See Models Used On For Details)
$42.58
9 019-6019-00 019-6019-00 - Spring blade cupped washer bot tom spindle
$9.23
10 019-5007-00 019-5007-00 - 1/2 Lockwasher Zinc
$2.99
11 033-5001-00 033-5001-00 - 5 3/4" Flat Idler Double Width Pulley
$56.77
12 018-6036-00 018-6036-00 - 1/2-13 X 2-3/4 GR 5 Bolt Zinc
$2.99
13 018-6059-00 018-6059-00 - 5/8-11 X 2-1/2 GR 5 Hex Bolts
$2.99
14 013-7021-00 013-7021-00 - 5/8-11 Nylon Insert Locknut Zi nc Orange Nylon
$2.99
15 014-6004-00 014-6004-00 - Metal Spindle Cover (See Models Used On For Details)
$42.58
16 013-8049-00 013-8049-00 - 5/16-18 Nylon Flange Nut
$2.99
17 039-4864-00 039-4864-00 - Discharge Chute Upper Hanger Plate (See Models Used On For Detail)
$42.52
18 210-5218-00 210-5218-00 - 48/52 Rubber Discharge Chute A ssy (obsolete)
use part #210-6005-48
$181.89
19 018-4703-00 018-4703-00 - 5/16-18 X 1-1/4 Carriage Bolt
$2.99
20.1 210-6005-48 210-6005-48 - Chute Assembly (See Models Used On For Detail)
$181.89
20 210-6005-00 210-6005-00 - Rubber Discharge Chute (See Models Used On For Detail)
$59.91
21 019-6042-00 019-6042-00 -.360 ID Plastic Washer
$2.99
22 013-5041-00 013-5041-00 - 3/8-16 Nylon Insert Locknut Zi nc Orange Nylon
$2.99
23 060-4800-98 060-4800-98 - 2007-2012 ZT/CZT 50" and 2013 ZT 48" - Complete Deck w/spindles (obsolete)
use part #060-6048-98
$2139.99
24 022-1000-98 022-1000-98 - Deck Wheel Assembly
$25.99
26 013-8050-00 013-8050-00 - 1/2-13 Nylon Insert Flange Nut Zinc Orange Nylon
$2.99
28.1 038-5000-00 038-5000-00 - 48"/50" Gator Mulching Blade
$22.99
28 038-5350-00 038-5350-00 - 48"/50" High Lift Fusion Blade
$22.99
29 019-4807-00 019-4807-00 - 5/8 Lockwasher Zinc
$2.99
30 018-6020-00 018-6020-00 - 5/8-18 X 1-1/2 GR 8 Hex Bolts Zinc Yellow for Blade Spindle
$2.99
31 018-5043-00 018-5043-00 - 3/8-16 X 1-1/4 Carriage Bolt
$2.99
32 045-6043-00 045-6043-00 - 5/16 Black Plastic Knob Spindle Cover
$4.39
33 024-6034-00 024-6034-00 - 1/4 Drive-in Grease Fitting
$2.99
34 018-7016-00 018-7016-00 - 1/2-13 X 3 GR 5 Hex Bolts Zinc
$2.99
35 025-5203-00 025-5203-00 - Spacer 3/4ODx1/2IDx0.75 Susp f ork
$3.29
36 039-6936-00 039-6936-00 - Deck Idler Bracket
$39.74
37 014-4801-00 014-4801-00 - 1/2 Metal Spindle Cover - Right (See Models Used On For Details)
$42.58
38 013-5202-00 013-5202-00 - 3/8 Nylock Flange Nut
$2.99
39 019-5029-00 019-5029-00 - 3/8 USS Flat Washer Zinc
$2.99
40 018-6019-00 018-6019-00 - 1/2-20 X 1-1/2 GR 5 Bolts Zinc, Fine Thread Bolt
$2.99
41 048-6056-00 048-6056-00 - Toplink/Turnbuckle-Deck Adjust (See Models Used On For Details)
$53.49
42 034-9035-00 034-9035-00 - Deck Idler Spring
$17.11
43 060-4800-00 060-4800-00 - 2007-2012 ZT/CZT 50" and 2013 ZT 48" Deck Shell Only (obsolete)
use part #060-6048-00
$1279.87
44 047-6050-00 047-6050-00 - CZT/ZT Deck Hanger Chain Assembly (See Models Used On For Details)
$8.74
45 018-6012-00 018-6012-00 - 3/8 x 1 1/2 Bolt
$2.99
46 041-1470-00 041-1470-00 - B147 Deck Belt (See Models Used On For Details)
$87.39
47 031-6020-00 031-6020-00 - Deck Hanger-Black - (Replaces 031-5351-00 - 031-5352-00 - 031-6000-00 - 031-6010-00)
$141.97
48 022-1000-00 022-1000-00 - Deck Wheel Only
$17.11
