2017 Walk Behind 36" Deck Assembly

36" Deck Assembly

The Bad Boy Mower 36" Deck Assembly for the 2017 Walkbehind is shown below. You may select the item you need by clicking on the Bad Boy Parts item number in the diagram or by finding it in the list below the diagram. BadBoyMowerParts.com has the bad boy mowers parts diagrams for the 2017 Walkbehind models as well. Find all of your Bad Boy mowers 2017 Walkbehind parts here. We are your BadBoy mower parts source. Thanks for shopping with us for all of your Bad Boy parts needs. If you are not able to find the Bad Boy parts for your 2017 Walkbehind please contact us using our Bad Boy parts live chat or toll free at 318.654.8520.

Bad Boy Mower Parts Lookup

2017 Walk Behind 36" Deck Assembly
  Position Number SKU Product Title Price
1 060-3600-00 060-3600-00 - 36" Welded Assembly
$641.99
2 037-6015-50 037-6015-50 - Spindle Assembly (See Models Used On For Detail)
$213.99
3 033-6003-00 033-6003-00 - 5" Spindle Deck Pulley - DB-80 (without set screw) (See Models Used On For Details)
$42.58
4 042-6030-00 042-6030-00 - 1/4 x 1 Square Key
$4.81
5 030-0050-00 030-0050-00 - 5/16 Set Screw
$2.99
6 018-6019-00 018-6019-00 - 1/2-20 X 1-1/2 GR 5 Bolts Zinc, Fine Thread Bolt
$2.99
7 019-5007-00 019-5007-00 - 1/2 Lockwasher Zinc
$2.99
8 019-6020-00 019-6020-00 - 1/2 Belleville Washer #K2000-G -150
$5.16
9 019-5037-00 019-5037-00 - 3/8 Lockwasher Zinc
$2.99
10 013-6014-00 013-6014-00 - 3/8-16 Hex Nuts Zinc
$2.99
11 018-6020-00 018-6020-00 - 5/8-18 X 1-1/2 GR 8 Hex Bolts Zinc Yellow for Blade Spindle
$2.99
12.1 038-0003-00 038-0003-00 - 54" & 2024 Raider 36" Deck Gator Mulching Blade
$22.99
12 038-0001-00 038-0001-00 - 54" & 2024 Raider 36" High Lift Fusion Blade
$22.99
13 018-6012-00 018-6012-00 - 3/8 x 1 1/2 Bolt
$2.99
14 031-0023-00 031-0023-00 - 2017-2022 Walk Behind Deck Hanger
$47.03
15 013-8050-00 013-8050-00 - 1/2-13 Nylon Insert Flange Nut Zinc Orange Nylon
$2.99
16 033-5000-00 033-5000-00 - 5 3/4" Double Bearing Flat Idler Pulley
$56.77
17 018-5311-00 018-5311-00 - 5/8-11 X 4 GR 5 Hex Bolts Zinc
$4.06
18 019-6017-00 019-6017-00 -.630 ID X 1.122 OD X.142 THK Flat Washer Nylon
$2.99
19 025-5203-00 025-5203-00 - Spacer 3/4ODx1/2IDx0.75 Susp f ork
$3.29
20 039-6945-00 039-6945-00 - Idler Arm Bracket
$40.53
21 018-7016-00 018-7016-00 - 1/2-13 X 3 GR 5 Hex Bolts Zinc
$2.99
22 013-5301-00 013-5301-00 - 5/8-11 Nylon Insert Jam Locknu t Zinc
$2.99
23 013-7018-00 013-7018-00 - 1/2-13 Hex Nuts Zinc
$2.99
24 018-2004-50 018-2004-50 -2017-2022 All Thread (See Models Used On)
$12.94
25 034-2020-00 034-2020-00 - Idler Spring (See Models Used On For Detail)
$17.11
26 039-4870-00 039-4870-00 - 48/52 Discharge Top Bracket Ru bber Chute Assembly
$42.52
27 039-4871-00 039-4871-00 - 48/52 Discharge Lower Bracket Rubber Chute
$32.65
28.1 210-6005-48 210-6005-48 - Chute Assembly (See Models Used On For Detail)
$181.89
28 210-6005-00 210-6005-00 - Rubber Discharge Chute (See Models Used On For Detail)
$59.91
29 013-8049-00 013-8049-00 - 5/16-18 Nylon Flange Nut
$2.99
30 018-4703-00 018-4703-00 - 5/16-18 X 1-1/4 Carriage Bolt
$2.99
31 206-6017-00 206-6017-00 - Discharge Chute Hanger-Deck (See Models Used On For Detail)
$39.03
32 018-2007-00 018-2007-00 - 5/16-18 X 1 GR 5 Hex Bolt Zinc
$2.99
33 019-6042-00 019-6042-00 -.360 ID Plastic Washer
$2.99
34 018-5250-00 018-5250-00 - 3/8-16 X 3/4 GR 5 Hex Bolts
$2.99
35 013-5201-00 013-5201-00 - 3/8-16 Hex Flange Nuts Zinc w/ Serrations
$2.99
36 024-6034-00 024-6034-00 - 1/4 Drive-in Grease Fitting
$2.99
37 041-0121-00 041-0121-00 - 36" Walk Behind Deck Belt 91" 5L/B
$74.89
38 019-5038-00 019-5038-00 - 5/8 Flat Washer
$2.99
39 026-0025-00 026-0025-00 - Deck Spindle Support Plate
$14.19
40 088-0020-00 088-0020-00 - Walk Behind Sulky Assembly
$534.99
