2017 ZT Elite Engine - Kohler KT740 & KT745

Engine - Kohler KT740 & KT745

The Bad Boy Mower Engine - Kohler KT740 & KT745 for the 2017 ZT Elite is shown below. You may select the item you need by clicking on the Bad Boy Parts item number in the diagram or by finding it in the list below the diagram. BadBoyMowerParts.com has the bad boy mowers parts diagrams for the 2017 ZT Elite models as well. Find all of your Bad Boy mowers 2017 ZT Elite parts here. We are your BadBoy mower parts source. Thanks for shopping with us for all of your Bad Boy parts needs. If you are not able to find the Bad Boy parts for your 2017 ZT Elite please contact us using our Bad Boy parts live chat or toll free at 318.654.8520.

Bad Boy Mower Parts Lookup

2017 ZT Elite Engine - Kohler KT740 & KT745
  Position Number SKU Product Title Price
1A 063-2000-06 063-2000-06 - Kohler 7000 Series Engine Service Kit
$94.47
1 033-5035-00 033-5035-00 - 4 3/4 Motor Pulley w/ Extended Shaft (See Models Used On For Details)
$42.58
2 018-1075-00 018-1075-00 - 3/8 x 1 1/8 Engine Mounting Bolt
$2.99
3 042-5020-00 042-5020-00 - 1/4 X 2 Square Key Stock
$2.99
4 015-2751-00 015-2751-00 - Exhaust Gasket for 27,30 hp Kohler Engines
$6.56
5 051-5401-00 051-5401-00 - Kohler/Briggs Oil Drain Hose
$31.17
6 041-6400-00 041-6400-00 - Pump Belt (See Models Used On For Details)
$58.84
7 030-0050-00 030-0050-00 - 5/16 Set Screw
$2.99
8 064-0030-00 064-0030-00 - 24 inch Black Cable
$18.72
9 015-2020-00 015-2020-00 - 25hp Kohler-48" 2014-2022 ZT KT740-3030
$2138.93
10 103-5400-00 103-5400-00 - Black Cable Boot
$4.37
11 019-8051-00 019-8051-00 - 5/16 Lockwashwer Zinc
$2.99
12 015-8000-00 015-8000-00 - Spark Plug-Kohler Briggs
$10.99
13 070-0056-00 070-0056-00 - PTO Clutch (See Models Used On For Details)
$390.38
14 019-6020-00 019-6020-00 - 1/2 Belleville Washer #K2000-G -150
$5.16
15 018-5450-00 018-5450-00 - 7/16-20 x 1 1/2 Fine Thread Bolt Gr8
$2.99
16 015-0051-00 015-0051-00 - 2017-2022 Kohler Exhaust MZ/ZT/Maverick
$232.70
17 013-8043-00 013-8043-00 - 5/16-18 Hex Nuts Zinc
$2.99
18 018-5350-00 018-5350-00 - 5/16-18 X 5-1/2 GR 5 Hex Bolt
$2.99
19 018-2007-00 018-2007-00 - 5/16-18 X 1 GR 5 Hex Bolt Zinc
$2.99
20 070-2000-00 070-2000-00 - Clutch Pigtail
$21.24
21 063-6000-00 063-6000-00 - Universal Inline Fuel Filter
$14.19
22 063-5400-00 063-5400-00 - Bad Boy Oil Filter (Long) - Kohler Engines
$20.32
23 063-5002-00 063-5002-00 - 25/26 HP Koh Precleaner ZT/MZ
$8.74
24 063-5003-00 063-5003-00 - 25/26 HP Koh Air Filter ZT/MZ
$26.74
25 015-2025-00 015-2025-00 - 26hp Kohler-2014 KT745-3031 (obsolete)
use part #015-2026-00
$2566.93
