2013 Diesels Seat Frame

Seat Frame

The Bad Boy Mower parts diagram for the 2013 Diesels Seat Frame is shown below. You may select the item you need by clicking on the Bad Boy Parts item number in the diagram or by finding it in the list below the diagram. BadBoyMowerParts.com has the parts diagrams for the 2013 Diesels models. Find all of your Bad Boy mowers 2013 Diesels parts here. We are your BadBoy mower parts source. Thanks for shopping with us for all of your Bad Boy parts needs. The Bad Boy parts diagram below is for the 2013 Diesels Seat Frame. If you are not able to find the Bad Boy parts for your 2013 Diesels please contact us using our Bad Boy parts live chat or toll free at 318.654.8520.

Bad Boy Mower Parts Lookup

2013 Diesels Seat Frame
  Position Number SKU Product Title Price
1A 085-4052-00 085-4052-00 - Pump/Wheel Motor Hydro Service Pack
$133.30
1 069-8054-00 069-8054-00 - Brake Handle Kit
$127.77
2 062-8013-00 062-8013-00 - Filter Head-Hydraulic Filter
$24.92
3 063-8014-00 063-8014-00 - Hydraulic Filter For Units with Pumps and Wheel Motors
$31.17
4 024-5050-00 024-5050-00 - Filter Head Fitting, 1/2 x 1/2 , 208-108
$8.01
5 077-8073-00 077-8073-00 - Safety Switch (See Models Used On For Detail)
$10.99
6 018-8059-00 018-8059-00 - 5/16-18x1-3/4 GR 5 Hex Bolts
$2.99
7 080-7000-00 080-7000-00 - 2007 Diesel Seat Frame
$427.99
9 018-8052-00 018-8052-00 - 1/4-20 X 3/4 GR 5 Hex Bolts
$2.99
10 019-4008-00 019-4008-00 - 1/4 Lockwasher Zinc
$2.99
11 013-9002-00 013-9002-00 - 5/16-18 Hex Flange Nuts Zinc w /Serrations
$2.99
12 025-6041-00 025-6041-00 - Switch Block Plastic
$2.99
13 064-8055-00 064-8055-00 - Short Brake Cable
$51.47
14 018-8056-00 018-8056-00 - 10-24x1/2 Buttonhead SCS 18-8
$2.99
16 066-8050-00 066-8050-00 - Hydraulic Tank Cap w/Dipstick (See Models Used On For Details)
$31.22
17 064-8056-00 064-8056-00 - Long Brake Cable
$53.49
18 051-8063-00 051-8063-00 - 3/8 Clear Hose PRICED PER FOOT
$2.99
19 051-8064-00 051-8064-00 - 1/2 Clear Braided Hose PRICED/ FOOT
$2.99
20A 055-2013-00 055-2013-00 - Throttle/Brake Head Ball
$12.48
20 055-2012-00 055-2012-00 - Universal Throttle/Brake Lever (Knob Not Included)
$25.54
21 055-8018-00 055-8018-00 - Throttle Cable (See Models Used On For Details)
$60.92
22 034-1000-00 034-1000-00 - Spring Cushion (See Models Used On For Detail)
$28.39
23 077-6000-00 077-6000-00 - Momentary Start Switch Preheat Button for Diesel
$21.39
24 014-6000-00 014-6000-00 - Start Switch Boot - Diesel
$4.87
25 021-8059-00 021-8059-00 - Heat Warning Piezo Buzzer
$36.37
26 015-0015-00 015-0015-00 - Auto Shut Down for Cat Diesels
$534.99
27 013-5019-00 013-5019-00 - 10-24 Nylon Insert Locknut Zin c Orange Nylon
$2.99
28 018-5200-00 018-5200-00 - 10-24 X 5/8 BS C/S 18-8 SS
$2.99
29 013-8039-00 013-8039-00 - 1/4-20 Hex Nuts Zinc
$2.99
30 072-8066-00 072-8066-00 - 1/2 Hose Clamp
$2.99
31 072-8065-00 072-8065-00 - 3/8 Hose Clamp - CTB-16-STFS
$2.99
32 019-5029-00 019-5029-00 - 3/8 USS Flat Washer Zinc
$2.99
33 013-5201-00 013-5201-00 - 3/8-16 Hex Flange Nuts Zinc w/ Serrations
$2.99
34 018-5040-00 018-5040-00 - 3/8-16 X 1-1/4 GR 5 Hex Bolt
$2.99
35 043-8929-00 043-8929-00 - Battery Hold Down Kit
$17.49
36 064-4001-00 064-4001-00 - Black Battery Cable (See Models Used On For Details)
$22.31
37 064-4000-00 064-4000-00 - Red Battery Cable (See Models Used On For Details)
$22.31
38 026-2006-00 026-2006-00 - Seat Plate (See Models Used On For Details)
$99.32
39 019-6042-00 019-6042-00 -.360 ID Plastic Washer
$2.99
40 013-8049-00 013-8049-00 - 5/16-18 Nylon Flange Nut
$2.99
41 018-8065-00 018-8065-00 - 5/16-18 X 1 Carriage Bolt Zinc
$2.99
42 071-4050-00 071-4050-00 - Grammer Suspension Seat Use w/o ROPS (obsolete)
use part #071-4050-17
$813.99
44 018-0011-00 018-0011-00 - 1/4-20 x 2 Hex Bolt
$2.99
46 013-9001-00 013-9001-00 - 1/4-20 Hex Flange Nuts Zinc w/ Serrations
$2.99
47 034-1075-00 034-1075-00 - Torsion Spring-Seat Latch
$5.49
49 031-0200-00 031-0200-00 - Seat Latch Lever
$2.99
50 018-0012-00 018-0012-00 - 5/16-18 X 2 HEX C/S (GR.5) ZC
$2.99
51 014-2009-00 014-2009-00 - 2012-2018 Diesel & 2011 Outlaw/Outlaw Extreme Cooler Cover
$126.20
52 030-7042-00 030-7042-00 - 5/16 x 3/4 Hex Washer Type F
$2.99
53 014-8047-00 014-8047-00 - Rubber Cap Cover
$8.93
54 034-8045-00 034-8045-00 - Seat Spring
$20.49
55 013-6014-00 013-6014-00 - 3/8-16 Hex Nuts Zinc
$2.99
56 019-5037-00 019-5037-00 - 3/8 Lockwasher Zinc
$2.99
57 018-6012-00 018-6012-00 - 3/8 x 1 1/2 Bolt
$2.99
58 018-2018-00 018-2018-00 - 1/2 x 3 1/2 Flange Bolt - Gr 8
$3.62
59 013-5300-00 013-5300-00 - 1/2-13 Hex Fange Nuts Zinc w/ Serrations
$2.99
60 036-5300-00 036-5300-00 - Seat Switch Adaptor
$15.55
61 071-4051-00 071-4051-00 - Left Armrest Kit-Grammer Seat
$124.87
62 071-4052-00 071-4052-00 - Right Armrest Kit-Grammer Seat
$88.76
