2010 MZ Engine - 21Hp Briggs Intek

Engine - 21Hp Briggs Intek

The Bad Boy Mower parts diagram for the 2010 MZ Engine (21Hp Briggs Intek) is shown below. You may select the item you need by clicking on the Bad Boy Parts item number in the diagram or by finding it in the list below the diagram. BadBoyMowerParts.com has the parts diagrams for the 2010 MZ models. Find all of your Bad Boy mowers 2010 MZ parts here. We are your BadBoy mower parts source. Thanks for shopping with us for all of your Bad Boy parts needs. The Bad Boy parts diagram below is for the 2010 MZ Engine (21Hp Briggs Intek). If you are not able to find the Bad Boy parts for your 2010 MZ please contact us using our Bad Boy parts live chat or toll free at 318.654.8520.

Bad Boy Mower Parts Lookup

2010 MZ Engine - 21Hp Briggs Intek
  Position Number SKU Product Title Price
1A 063-2000-08 063-2000-08 - MZ Briggs Intek 21HP Engine Service Kit
$94.79
1 015-0021-00 015-0021-00 - 540cc Briggs Intek Engine-MZ
$1925.99
2 033-2010-00 033-2010-00 - 3 3/4 Motor Pulley (See Models Used On For Details)
$31.22
3 041-6400-00 041-6400-00 - Pump Belt (See Models Used On For Details)
$58.84
4 018-8059-00 018-8059-00 - 5/16-18x1-3/4 GR 5 Hex Bolts
$2.99
5 019-8051-00 019-8051-00 - 5/16 Lockwashwer Zinc
$2.99
6 013-8043-00 013-8043-00 - 5/16-18 Hex Nuts Zinc
$2.99
7 064-0030-00 064-0030-00 - 24 inch Black Cable
$18.72
8 018-5051-00 018-5051-00 - OBSOLETE use 018-1075-00 3/8x1 1/8 HWH Engine Bolt (obsolete)
use part #018-1075-00
$2.99
10 019-6019-00 019-6019-00 - Spring blade cupped washer bot tom spindle
$9.23
11 018-0006-00 018-0006-00 - 7/16-20 X 3 HEX BOLTS GR 5 ZIN (obsolete)
use part #018-0007-00
$2.99
12 019-8053-00 019-8053-00 - 7/16 Lockwasher zinc
$2.99
13 042-6030-00 042-6030-00 - 1/4 x 1 Square Key
$4.81
14 070-3000-00 070-3000-00 - 2010-2014 MZ/ Magnum UNITS ONLY Ogura PTO Clutch - 100 ft/lbs
$299.59
15 057-5920-00 057-5920-00 - 2010-2014 MZ Clutch Holder
$21.28
16 018-8065-00 018-8065-00 - 5/16-18 X 1 Carriage Bolt Zinc
$2.99
17 013-8049-00 013-8049-00 - 5/16-18 Nylon Flange Nut
$2.99
19 063-4026-00 063-4026-00 - 21hp Briggs Air Filer and Pre-cleaner - MZ
$39.04
20 063-8018-00 063-8018-00 - Oil Filter
$21.39
21 015-8000-00 015-8000-00 - Spark Plug-Kohler Briggs
$10.99
22 063-6000-00 063-6000-00 - Universal Inline Fuel Filter
$14.19
