2013 Outlaw & Outlaw Extreme Actuator Bar

Actuator Bar

The Bad Boy Mower parts diagram for the 2013 Outlaw Actuator Bar is shown below. You may select the item you need by clicking on the Bad Boy Parts item number in the diagram or by finding it in the list below the diagram. BadBoyMowerParts.com has the parts diagrams for the 2013 Outlaw models. Find all of your Bad Boy mowers 2013 Outlaw parts here. We are your BadBoy mower parts source. Thanks for shopping with us for all of your Bad Boy parts needs. The Bad Boy parts diagram below is for the 2013 Outlaw Actuator Bar. If you are not able to find the Bad Boy parts for your 2013 Outlaw please contact us using our Bad Boy parts live chat or toll free at 318.654.8520.

Bad Boy Mower Parts Lookup

2013 Outlaw & Outlaw Extreme Actuator Bar
  Position Number SKU Product Title Price
1 070-5350-00 070-5350-00 - 2012-2014 Outlaw/Outlaw Extreme Frame
$1390.99
2 026-2100-00 026-2100-00 - Diesel & Outlaw Height Indicator Plate (Outer)
$12.83
3 040-4000-00 040-4000-00 - MZ, Diesel & Outlaw Deck Height Lever Pin
$17.16
4 031-0100-00 031-0100-00 - Deck Lever Lock (See Models Used On For Details)
$18.45
5 019-2003-00 019-2003-00 -.390x.750x.062 Nylon Washer
$2.99
6 018-0009-00 018-0009-00 - 3/8 x 1 3/4 Carriage Bolt
$2.99
7 025-5203-00 025-5203-00 - Spacer 3/4ODx1/2IDx0.75 Susp f ork
$3.29
8 013-5202-00 013-5202-00 - 3/8 Nylock Flange Nut
$2.99
9 039-6945-00 039-6945-00 - Idler Arm Bracket
$40.53
11 033-6001-00 033-6001-00 - 4 3/4 Idler Pulley (See Models Used On For Details)
$31.22
12 018-7016-00 018-7016-00 - 1/2-13 X 3 GR 5 Hex Bolts Zinc
$2.99
13 025-7036-00 025-7036-00 - 1/2 Set Collar w/set collar
$4.60
14 013-8050-00 013-8050-00 - 1/2-13 Nylon Insert Flange Nut Zinc Orange Nylon
$2.99
15 024-6034-00 024-6034-00 - 1/4 Drive-in Grease Fitting
$2.99
16 034-2009-00 034-2009-00 - Deck/Pump Idler Spring (See Models Used On For Detail)
$18.18
17 018-2004-00 018-2004-00 - All Thread-Pump Idler Tensione
$12.94
18 013-7021-00 013-7021-00 - 5/8-11 Nylon Insert Locknut Zi nc Orange Nylon
$2.99
19 019-6017-00 019-6017-00 -.630 ID X 1.122 OD X.142 THK Flat Washer Nylon
$2.99
20 013-7018-00 013-7018-00 - 1/2-13 Hex Nuts Zinc
$2.99
21 018-4010-00 018-4010-00 - 1/2-13 Nylon Insert Jam Locknu t Zinc Orange Nylon
$2.99
22 028-6020-00 028-6020-00 - Rear Actuator Bar Assy (See Models Used On For Detail)
$106.48
23 032-3000-00 032-3000-00 - Actuator Bar Bushing
$2.99
24 028-6010-00 028-6010-00 - Front Actuator Bar Assy (See Models Used On For Detail)
$152.99
25 028-6050-00 028-6050-00 - Outlaw Deck Linkage Rod
$28.39
26 017-7008-00 017-7008-00 - 1" Pillow Block Bearing
$21.29
27 018-5006-00 018-5006-00 - 1/2-13 X 1-1/2 GR 5 Hex Bolt, Coarse Thread Bolt (For Use On Spindles Please Refer To Item Details)
$2.99
28 018-5007-00 018-5007-00 - 5/16-18 X 3/4 Button Head Sock et C/S 18-8 SS
$2.99
30 018-2050-00 018-2050-00 - 10mm Damper Ball Stud-Steering Damper, Outlaw Deck Damper
$2.99
32 018-0008-00 018-0008-00 - 1/2 x 1 1/2 Carriage Bolt
$2.99
33 087-5400-00 087-5400-00 - 200lb Gas Spring - 54" Outlaw Deck Damper
$62.40
34 018-2049-00 018-2049-00 - 13mm Ball Stud for 72" Deck Damper for Outlaw
$4.83
35 013-9002-00 013-9002-00 - 5/16-18 Hex Flange Nuts Zinc w /Serrations
$2.99
36 026-2110-00 026-2110-00 - Outlaw Rear Plate
$213.99
37 018-5043-00 018-5043-00 - 3/8-16 X 1-1/4 Carriage Bolt
$2.99
38 013-5041-00 013-5041-00 - 3/8-16 Nylon Insert Locknut Zi nc Orange Nylon
$2.99
39 072-8067-00 072-8067-00 - 5/8 Hose Clamp SS
$2.99
40 051-9000-00 051-9000-00 - 5/8 Braided Hose Priced per Foot
$4.81
41 066-5050-00 066-5050-00 - Hydraulic Tank Cap (See Models Used On For Details)
$15.60
42 019-8040-00 019-8040-00 - 1/4 x 3/4 Carriage Bolt
$2.99
43 013-2050-00 013-2050-00 - 1/4-20 Nylon Insert Flange Nut
$2.99
44 067-8085-00 067-8085-00 - Expansion Tank for Outlaw (See Models Used On For Details)
$31.22
45 029-7037-00 029-7037-00 - 14 Bumper
$42.79
46 018-4702-00 018-4702-00 - 1/4-20 X 1-1/4 GR 5 Hex Bolt
$2.99
47 019-7040-00 019-7040-00 - 1/4 USS Flat Washer Zinc
$2.99
48 026-0013-00 026-0013-00 - 2010-2018 Outlaw & 2012-2018 Compact Diesel Deck Lift Pedal
$21.28
49 040-5000-00 040-5000-00 - Pull Pin - Foot Assist w/Ring
$21.39
50 201-1050-00 201-1050-00 - Spoiler Support Right
$35.48
51 201-1051-00 201-1051-00 - Spoiler Support Left
$35.48
52 026-1040-00 026-1040-00 - Outlaw Spoiler Plate
$106.99
53 018-8065-00 018-8065-00 - 5/16-18 X 1 Carriage Bolt Zinc
$2.99
54 030-0010-00 030-0010-00 - 5/16-18 x 1 Thumb Screw Zinc (No Shoulder)
$3.29
55 087-7200-00 087-7200-00 - 300 lb Gas Spring -72" Outlaw Deck Damper
$62.40
56 087-6100-00 087-6100-00 - 250lb Gas Spring - 61" Outlaw Deck Damper
$78.01
